Wireless Router, MERCUSYS, Router, LAN \ WAN ports 1, 4G, MB230-4G
Product reference: 2-6957939001827

Wireless Router, MERCUSYS, Router, LAN \ WAN ports 1, 4G, MB230-4G

Product reference: 2-6957939001827
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
6420
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Faster and Smoother
with 4G+ Speed and
Dual Band WiFi

4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router

Plug Your Nano SIM Card and Play
Fully compatible with FDD-LTE and TDD-LTE to work with most service providers worldwide. Insert a nano SIM card and turn on the router to share your 4G LTE network with multiple Wi-Fi devices.

Get Wi-Fi Where You Need It
Enjoy unmatched convenience and versatility and the utilize fast and stable Wi-Fi, whether you're at home or working remote.

Extra Fast 4G+ Cat 6 Speed for Reliable Wi-Fi
MB230-4G supports the 4G+ Cat 6, which uses Carrier Aggregation technology, to achieve superfast LTE speeds up to 300 Mbps download and 50 Mbps upload. It can also share a dual band Wi-Fi network for gaming, streaming, and more.

Share the WiFi with Friends
An remarkable number of wireless gadgets are compatible with this 4G router without any issues. Up to 64 simultaneous connections for tablets, laptops, mobile phones, and other devices.

Full with Strong and Stable Signal
Internal high gain antennas strengthen the WiFi signal, extend the range of connection establishment, and boost the sensitivity of the router.

Available WAN Connection Backup
With a fully functional WAN/LAN port, MB230-4G can work as a router which is compatible with cable, fiber, and DSL modems, or provide internet for wired devices. The reliable access is for up to 64 devices Simultaneously.

Easy Setup and Management via MERCUSYS App
Set up and manage your Wi-Fi through the MERCUSYS app from your smartphone (Android, iOS).

  • 4G+ network - Enjoy the 4G+ Cat 6 download speeds up to 300 Mbps
  • Plug a SIM card and play - No configurations needed, compatibility of SIM cards are assured by years of field tests
  • Dual Band 1200 Mbps WiFi - Fast WiFi speeds up to 300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band
  • Simultaneous Connection- Enjoy and share internet access with up to 64 Wi-Fi devices
  • Wi-Fi router mode - Plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection

Summary Mercusys 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 1200 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Mobile network generation: 4G, 3G standards: HSPA, HSPA+, UMTS, 4G standard: LTE-TDD & LTE-FDD. Security algorithms: 64-bit WEP, WPA-PSK, WPA2-PSK, WPA3-SAE
Vendor Homepage https://www.mercusys.com/uk/product/details/mb230-4g
Unit Box Height 0.21
Unit Box Length 0.11
Unit Box Width 0.13
Top Wi-Fi standard Wi-Fi 5 (802.11ac)
Wi-Fi band Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max) 1200 Mbit/s
3G/4G USB modem compatibility Yes
DSL WAN No
Ethernet WAN Yes
SIM card slot Yes
WAN connection type RJ-45
Cabling technology 10/100/1000Base-T(X)
Dynamic DNS (DDNS) Yes
Ethernet LAN Yes
Ethernet LAN data rates 10/100/1000 Mbit/s
Ethernet LAN interface type Gigabit Ethernet
Networking standards IEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n
Port forwarding Yes
Port triggering Yes
Receiver sensitivity 11g 6Mbps: -95dBm; 11g 54Mbps: -77dBm; 11n HT20 MCS7: -74dBm; 11n HT40 MCS7: -71dBm; 11a 6Mbps: -92dBm; 11a 54Mbps: -75dBm; 11ac VHT20 MCS8: -70dBm; 11ac VHT40 MCS9: -65dBm; 11ac VHT80 MCS9: -61dBm
3G bands supported 2100/850/900 MHz
3G standards HSPA/HSPA+/UMTS
4G bands supported 1800/2100/2300/2600/700/800/850/900 MHz
4G standard LTE-TDD & LTE-FDD
Dual SIM support No
Mobile network generation 4G
SIM card type NanoSIM
DC-in jack Yes
Ethernet LAN (RJ-45) ports 2
USB port No
Reset button Yes
Wi-Fi Multimedia (WMM)/(WME) Yes
WPS push button Yes
DMZ support Yes
Firewall Yes
Port-based Network Access Control (PNAC) Yes
Security algorithms 64-bit WEP/WPA2-PSK/WPA3-SAE/WPA-PSK
System event log Yes
DHCP server Yes
Universal Plug and Play (UPnP) Yes
VoIP protocols IPv4, IPv6
Indication light Yes
Product colour White
Product type Desktop/pole router
AC adapter included Yes
Quick installation guide Yes
Antenna design Internal
Firmware upgradeable Yes
Output current 1 A
Output voltage 12 V
Power source type DC
Operating relative humidity (H-H) 10 - 90 %
Operating temperature (T-T) 0 - 40 °C
Storage relative humidity (H-H) 5 - 90 %
Storage temperature (T-T) -40 - 60 °C
Depth 61.05 mm
Height 165.97 mm
Width 95 mm
Number of products included 1 pc(s)
Package type Box
Model name MB230-4G
Units per Shipping Box 12
Unit Calculated Volume 0.003658 cubm
Unit Calculated Weight 0.625 kg
