UBIQUITI Wall-mountable UniFi Cloud Gateway, WiFi 6 AP, PoE Switch, NVR, Dream Wall
Product reference: 18-UDW

UBIQUITI Wall-mountable UniFi Cloud Gateway, WiFi 6 AP, PoE Switch, NVR, Dream Wall

UBIQUITI Wall-mountable UniFi Cloud Gateway, WiFi 6 AP, PoE Switch, NVR, Dream Wall

Product reference: 18-UDW

UBIQUITI Wall-mountable UniFi Cloud Gateway, WiFi 6 AP, PoE Switch, NVR, Dream Wall

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
1 07447
Last product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!
Fill in the required fields*

Wall-mounted UniFi OS Console with a security gateway, a PoE switch including four 802.3bt PoE++ ports, a high-performance access point, and a network video recorder.


The Dream Wall is a powerful, wall-mounted UniFi OS Console designed to be a standalone, space-saving deployment hosting solution. This feature-rich, next-gen console is equipped with (17) GbE RJ45 ports, including (12) with PoE output[(4) PoE, (4) PoE+, and (4) PoE++], (3) multi-gigabit WAN/LAN ports, and a dual-band Wi-Fi radio with a 2.7 Gbps aggregate throughput rate to give you the power to build reliable, fast networks that support a variety of local and remote clients. The Dream Wall also has a 1.3' LCM color touchscreen for convenient status monitoring and a built-in Bluetooth management radio to expedite your setup and configuration process via the UniFi Network web or mobile application. UDM is equipped with a Micro SD card slot that requires a memory card with at least 128GB of storage. The Dream Wall comes with one pre-installed PSU.



















































































































































































































Mechanical
Dimensions549 x 342 x 62 mm (21.6 x 13.5 x 2.4')
Weight8.6 kg (19 lbs)
Enclosure materialsPolycarbonate, galvanized steel, aluminum alloy
Mounting materialStainless steel
Hardware
ProcessorQuad-core ARM® Cortex®-A57 at 1.7 GHz
System memory4GB DDR4
On-board storage16 GB eMMC Integrated 128 GB SSD Pre-installed 512 GB microSD card
Expansion slotMicro SD memory card* *Requires a memory card with at least 128 GB of storage.
Management interfaceEthernet Bluetooth WiFi
Network interface(17) LAN: GbE RJ45 port (1) WAN: 2.5 GbE RJ45 port
SFP+ interface(1) LAN: 10G SFP+ port (1) WAN: 10G SFP+ port
PoE interface(4) PoE (Pair A 1, 2+; 3, 6-) (4) PoE+ (Pair A 1, 2+; 3, 6-) (4) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Power methodUniversal AC input 100—240V AC, 7A Max., 50/60Hz
Power supply(2) Hot-Swappable AC/DC 550W PSU* *Comes with (1) pre-installed PSU.
Max. power consumption532W
Max. PoE wattage per port by PSEPoE: 15.4W PoE+: 30W PoE++: 60W
Voltage range PoE modePoE: 44—57V PoE+/PoE++: 50—57V
Max. TX power 2.4 GHz 5 GHz23 dBm 26 dBm
MIMO 2.4GHz 5GHz2x2 4x4
Throughput rate 2.4 GHz 5 GHz300Mbps 2.4Gbps
Antenna gain 2.4 GHz 5 GHz5.9 dBi 6 dBi
ESD/EMP protectionAir: ± 8kV, contact: ± 4kV
LCD display(1) 4.7' touchscreen
ButtonFactory reset
MountingWall mount (included)
Operating temperature-10 to 40°C (14 to 104°F)
Operating humidity5 to 95% non-condensing
CertificationsCE, FCC, IC
Gateway Features
PerformanceRedundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Additional internet failover with LTE Backup Internet quality and outage reporting
Next-generation securityApplication-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall
Advanced networkingLicense-free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport and Identity VPN Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IGMP proxy IPv6 ISP support
Software
WiFi standards802.11a/b/g WiFi 4/WiFi 5/WiFi 6
Wireless securityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID8 on the radio
VLANs802.1Q
Advanced QoSPer-user rate limiting
Guest traffic isolationSupported
Concurrent clients300+
LEDs
EthernetWhite: link/activity
SFP+White: link/activity
PSUBlue: ready Amber: failure
Supported Data Rates
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
