UBIQUITI prie sienos montuojamas UniFi debesies šliuzas, WiFi 6 prieigos taškas, PoE komutatorius, NVR, „Dream Wall“
Prekės kodas: 18-UDW

UBIQUITI prie sienos montuojamas UniFi debesies šliuzas, WiFi 6 prieigos taškas, PoE komutatorius, NVR, „Dream Wall“


UBIQUITI prie sienos montuojamas UniFi debesies šliuzas, WiFi 6 prieigos taškas, PoE komutatorius, NVR, „Dream Wall“

Prekės kodas: 18-UDW

UBIQUITI prie sienos montuojamas UniFi debesies šliuzas, WiFi 6 prieigos taškas, PoE komutatorius, NVR, „Dream Wall“


Jūsų palyginimo sąraše yra 3 prekės, prašome vieną pašalinti ir bandyti dar kartą.
  • Įtraukti į patikusias prekes
  • Pridėta į patikusias prekes
  • Pašalinta iš patikusų prekių
Įtraukti į palyginimą
1 084,80 €
Paskutinė prekė

Garantija
12 mėn.

Pristatymas iš Lietuvos
per 2 - 4*
d. d.

Jūsų žinutė sėkmingai išsiųsta!
Užpildykite privalomus laukus*

Wall-mounted UniFi OS Console with a security gateway, a PoE switch including four 802.3bt PoE++ ports, a high-performance access point, and a network video recorder.


The Dream Wall is a powerful, wall-mounted UniFi OS Console designed to be a standalone, space-saving deployment hosting solution. This feature-rich, next-gen console is equipped with (17) GbE RJ45 ports, including (12) with PoE output[(4) PoE, (4) PoE+, and (4) PoE++], (3) multi-gigabit WAN/LAN ports, and a dual-band Wi-Fi radio with a 2.7 Gbps aggregate throughput rate to give you the power to build reliable, fast networks that support a variety of local and remote clients. The Dream Wall also has a 1.3' LCM color touchscreen for convenient status monitoring and a built-in Bluetooth management radio to expedite your setup and configuration process via the UniFi Network web or mobile application. UDM is equipped with Micro SD card slot that requires a memory card with at least 128GB of storage. The Dream Wall comes with one pre-installed PSU.


Mechanical
Dimensions 549 x 342 x 62 mm (21.6 x 13.5 x 2.4')
Weight 8.6 kg (19 lb)
Enclosure materials Polycarbonate, galvanized steel, aluminum alloy
Mount material Stainless steel
Hardware
Processor Quad-core ARM® Cortex®-A57 at 1.7 GHz
System memory 4 GB DDR4
On-board storage 16 GB eMMC

Integrated 128 GB SSD

Pre-installed 512 GB microSD card
Expansion slot Micro SD memory card*

*Requires a memory card with at least 128 GB of storage.
Management interface Ethernet

Bluetooth

WiFi
Networking interface (17) LAN: GbE RJ45 ports

(1) WAN: 2.5 GbE RJ45 port
SFP+ interface (1) LAN: 10G SFP+ port

(1) WAN: 10G SFP+ port
PoE interface (4) PoE (Pair A 1, 2+; 3, 6-)

(4) PoE+ (Pair A 1, 2+; 3, 6-)

(4) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Power method Universal AC input 100—240V AC, 7A Max., 50/60Hz
Power supply (2) Hot-Swappable AC/DC 550W PSU*

*Comes with (1) pre-installed PSU.
Max. power consumption 532W
Max. PoE wattage per port by PSE PoE: 15.4W

PoE+: 30W

PoE++: 60W
Voltage range PoE mode PoE: 44—57V

PoE+/PoE++: 50—57V
Max. TX power

2.4 GHz

5 GHz
23 dBm

26 dBm
MIMO

2.4 GHz

5 GHz
2 x 2

4 x 4
Throughput rate

2.4 GHz

5 GHz
300 Mbps

2.4 Gbps
Antenna gain

2.4 GHz

5 GHz
5.9 dBi

6 dBi
ESD/EMP protection Air: ± 8kV, contact: ± 4kV
LCM display (1) 4.7' touchscreen
Button Factory reset
Mounting Wall mount (included)
Operating temperature -10 to 40° C (14 to 104° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Gateway Features
Performance Redundant WAN with failover and load balancing

WiFi QoS with UniFi APs

Application, domain, and country-based QoS

Application and device type identification

Additional internet failover with LTE Backup

Internet quality and outage reporting
Next-generation security Application-aware firewall rules

Signature-based IPS/IDS threat detection

Content, country, domain, and ad filtering

VLAN/subnet-based traffic segmentation

Full stateful firewall
Advanced networking License-free SD-WAN

WireGuard, L2TP and OpenVPN server

OpenVPN client

OpenVPN and IPsec site-to-site VPN

One-click Teleport and Identity VPN

Policy-based WAN and VPN routing

DHCP relay

Customizable DHCP server

IGMP proxy

IPv6 ISP support
Software
WiFi standards 802.11a/b/g

WiFi 4/WiFi 5/WiFi 6
Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
LEDs
Ethernet White: link/activity
SFP+ White: link/activity
PSU Blue: ready

Amber: failure
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
