UBIQUITI UniFi Switch Flex Mini 2.5G

High-Speed ​​Network SwitchingThe Ubiquiti Flex Mini 2.5G (USW-Flex-2.5G-5) is a compact and efficient 5-port switch that brings high-speed networking capabilities to any environment. With four 2.5 GbE ports, this switch ensures faster data transmission, making it an excellent choice for modern networking applications that require quick and reliable connectivity. The 2.5 GbE PoE input port facilitates effortless power sourcing via Power over Ethernet, eliminating the need for additional power adapters or outlets. For added versatility, the switch can also be powered using the included 5V, 1A USB-C adapter, making it easy to integrate into various environments. This flexibility in power options ensures that the Flex Mini can be placed in various locations, making it a versatile addition to your network.

Optimized PerformanceDesigned for seamless performance, the Ubiquiti Flex Mini offers a total non-blocking throughput of 12.5 Gbps and a switching capacity of 25 Gbps. These specifications ensure that data can flow freely without bottlenecks, even under heavy load. The forwarding rate of 18.6 million packets per second (Mpps) allows the switch to handle high traffic volumes efficiently, making it suitable for demanding applications such as video streaming, online gaming, and large file transfers. Additionally, its support for Layer 2 switching features enhances network performance and stability, including Spanning Tree Protocol (STP), Rapid Spanning Tree Protocol (RSTP), port isolation, and storm control, which help manage and optimize network traffic effectively.

Easy ManagementThe Flex Mini prioritizes user convenience, offering an Ethernet In-Band management interface that simplifies both setup and configuration tasks. This functionality allows users to manage the switch directly through their existing network without the need for additional software or equipment. The application requirements specify compatibility with UniFi Network version 8.4.62 and later, ensuring that users can take advantage of the latest features and enhancements. Whether used in a home office, a small business, or an enterprise setting, the Ubiquiti Flex Mini 2.5G provides a reliable and powerful networking solution tailored to meet the demands of today's digital landscape.

Overview

Dimensions: 117.1 x 90 x 21.2 mm (4.6 x 3.5 x 0.8') Port Layout: 2.5 GbE RJ45 x5 Form Factor: Compact desktop

Performance

Switching Capacity: 24 Gbps Total Non-Blocking Throughput: 12.5 Gbps Forwarding Rate: 19 Mpps Supported VLANs: 256 MAC Address Table Size: 4,000

Layer 2 Features

STP RSTP: Yes Egress Rate Limit: Yes Flow Control: Yes Storm Control: Yes Multicast Broadcast Rate Limiting: Yes Port Isolation: Yes Port Mirroring: Yes Jumbo Frames: Yes Loop Protection: Yes

Hardware

Max. Power Consumption: 5W (AC/DC input) 6.4W (PoE input) Power Method: (1) USB Type-C, 5V DC, 1A (1) PoE Power Input Method: USB Input PoE Power Supply: AC/DC, external, 5W Supported Voltage Range: 4.8—5.2V DC/USB 44V—57V PoE Management: Ethernet Weight: 206 g (7.3 oz) Enclosure Material: Polycarbonate Ambient Operating Temperature: -20 to 45° C (-4 to 113° F) Ambient Operating Humidity: 10 to 90% noncondensing Certifications: CE, FCC, IC
