UBIQUITI UniFi Switch Flex 2.5G

Advanced Switching FeaturesThe Ubiquiti UniFi Switch Flex 2.5G (USW-Flex-2.5G-8) is engineered to provide robust and high-speed networking solutions for both home and business environments. Equipped with eight 2.5 Gigabit Ethernet (GbE) RJ45 ports, it ensures rapid data transfer rates, accommodating bandwidth-intensive applications such as high-definition video streaming, online gaming, and large file transfers. Additionally, the switch features a versatile 10 Gigabit Ethernet RJ45/SFP+ combination uplink port, offering flexible connectivity options to integrate seamlessly with existing network infrastructures. Beyond its impressive hardware capabilities, the USW-Flex-2.5G-8 offers advanced Layer 2 switching features to enhance network performance and security. These include support for Spanning Tree Protocol (STP/RSTP) with configurable priorities and port-level disable options, storm control, multicast and broadcast rate limiting, flow control, jumbo frames, egress rate limiting, proprietary loop protection, port isolation, and port mirroring. These features empower network administrators to optimize traffic management, prevent network loops, and maintain a robust and secure networking environment, catering to the demands of modern network infrastructures.

Flexible Power OptionsThe USW-Flex-2.5G-8 offers multiple power input methods to suit various deployment scenarios. It can be powered via a 5V, 3A USB-C adapter, providing a straightforward and accessible power solution. Alternatively, the switch supports Power over Ethernet Plus (PoE+), allowing it to receive power through the 10 GbE RJ45 uplink port when connected to a compatible PoE+ source. This flexibility simplifies installation and reduces cable clutter, making it an ideal choice for various networking setups. The USW-Flex-2.5G-8 boasts a sleek and compact form factor, measuring 212.9 x 76 x 33.5 mm and weighing 420 grams. Its polycarbonate enclosure ensures durability while maintaining a lightweight profile. The switch is designed for versatile mounting options, including wall mounting (kit included) and DIN rail mounting (sold separately), allowing for flexible placement in various environments. Its compact size and flexible installation options make it suitable for both space-constrained and open areas, ensuring optimal network deployment.

Overview

Dimensions: 212.9 x 76 x 33.5 mm (8.4 x 3 x 1.3') Port Layout: 2.5 GbE RJ45: 8 (2.5G/1G/100M/10M) 10 GbE RJ45: 1 (10G/5G/2.5G/1G/100M) 10G SFP+: 1 Form Factor: Compact Desktop, wall, DIN, magnetic

Performance

Switching Capacity: 60 Gbps Total Non-Blocking Throughput: 30 Gbps Forwarding Rate: 45 Mpps Supported VLANs: 256 MAC Address Table Size: 4,000

Layer 2 Features

STP RSTP: Yes Egress Rate Limit: Yes Flow Control: Yes Storm Control: Yes Multicast Broadcast Rate Limiting: Yes Port Isolation: Yes Port Mirroring: Yes Jumbo Frames: Yes Loop Protection: Yes

Hardware

Max. Power Consumption: 14W with PoE input 14W with AC adapter input Power Method: (1) USB Type-C, 5V DC, 3A (1) PoE+ Power Input Method: USB Input PoE Power Supply: AC/DC, external, 15W Supported Voltage Range: 4.8—5.2V DC/USB 44V—57V PoE Management: Ethernet Weight: 395 g (0.87 lb) Enclosure Material: Polycarbonate Mount Material: Polycarbonate Ambient Operating Temperature: -20 to 45° C (-4 to 113° F) Ambient Operating Humidity: 10 to 90% noncondensing NDAA Compliant: Yes Certifications: CE, FCC, IC

Software

Application Requirements: UniFi Network: Version 9.0.114 and later
