UBIQUITI 10 Ports 10 GbE and 2 Ports 10G SFP+ PoE+++ Switch Pro XG 10 PoE

1U, professional-grade 10-port, Layer 3 Etherlighting™ PoE+++ switch with (10) 10 GbE and (2) 10G SFP+ ports

Dimensions: 442.4 x 285 x 44 mm (17.4 x 11.2 x 1.7') Port Layout: 10 GbE RJ45: 10 (All PoE+++) (10G/5G/2.5G/1G/100M) 10G SFP+: 2 (10G/1G) Max. PoE Output: Up to PoE+++ (802.3bt Type 4, Class 8) Total PoE Availability: 400W Redundancy: DC Power Backup (With UniFi RPS) Layer 3: ✓ Form Factor: Rack mount (1U) Etherlighting™: ✓

Performance

Switching Capacity: 240 Gbps Total Non-Blocking Throughput: 120 Gbps Forwarding Rate: 179 Mpps Supported VLANs: 1,000 MAC Address Table Size: 32,000 L3 Table Size: ARP Entries: 12,000 IPv4 Routes: 12,000 Packet Buffer Size: 2 MB Access Lists: IPv4: 128 MAC: 128

Layer 3 Features

DHCP Server (Local Networks): ✓ DHCP Relay: ✓ Inter-VLAN Routing (Local Networks): ✓ Static Routing (Local Networks): ✓ LACP Port Aggregation: ✓ STP RSTP: ✓ QoS (DSCP): ✓ Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron): ✓ Advanced IGMP Configuration (Querier, Fast Leave, Router Port): ✓ IGMP Snooping: ✓ 802.1X Control: ✓ MAC-Based ACLs Device Isolation: ✓ DHCP Snooping Guarding: ✓ Egress Rate Limit: ✓ Flow Control: ✓ Storm Control: ✓ Multicast Broadcast Rate Limiting: ✓ MAC Address Blocking: ✓ IP-Based ACLs Network Isolation: ✓ MAC-Based Port Restriction: ✓ Port Isolation: ✓ Port Mirroring: ✓ Jumbo Frames: ✓ LLDP-MED: ✓ Voice VLAN: ✓ Loop Protection: ✓

Hardware

PoE Ports: PoE+++: 10 Max. PoE Wattage per Port by PSE: PoE: 15.4W PoE+: 30W PoE++: 60W PoE+++: 90W Max. Power Consumption: 65W (Excluding PoE output) 520W (Including PoE output) Power Method: (1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input Power Input Method: AC input Power Supply: AC/DC, internal, 550W Supported Voltage Range: 100—240V AC Management: Ethernet AR Weight: Without mounting brackets: 4.6 kg (10.14 lb) With mounting brackets: 4.7 kg (10.36 lb) Enclosure Material: SGCC steel Mount Material: SGCC steel Supported Rack Depth: 400~1200 mm (15.7-47.2'') LCM Display: 1.3' touchscreen ESD Protection: Air: ± 30kV, contact: ± 30kV Ambient Operating Temperature: -5 to 40° C (23 to 104° F) Ambient Operating Humidity: 10 to 90% noncondensing Etherlighting™: Ethernet: ✓ SFP+: ✓ LEDs: RPS: ✓ System: ✓ NDAA Compliant: ✓ Certifications: CE, FCC, IC Application Requirements: UniFi Network: Version 9.1.120 and later
