UBIQUITI 10 prievadų 10 GbE ir 2 prievadų 10G SFP+ PoE+++ komutatorius Pro XG 10 PoE

1U, professional-grade 10-port, Layer 3 Etherlighting™ PoE+++ switch with (10) 10 GbE and (2) 10G SFP+ ports

Dimensions: 442.4 x 285 x 44 mm (17.4 x 11.2 x 1.7')

Port Layout:

10 GbE RJ45: 10 (All PoE+++) (10G/5G/2.5G/1G/100M)

10G SFP+: 2 (10G/1G)

Max. PoE Output: Up to PoE+++ (802.3bt Type 4, Class 8)

Total PoE Availability: 400W

Redundancy: DC Power Backup (With UniFi RPS)

Layer 3: ✓

Form Factor: Rack mount (1U)

Etherlighting™: ✓

Performance

Switching Capacity: 240 Gbps

Total Non-Blocking Throughput: 120 Gbps

Forwarding Rate: 179 Mpps

Supported VLANs: 1,000

MAC Address Table Size: 32,000

L3 Table Size:

ARP Entries: 12,000

IPv4 Routes: 12,000

Packet Buffer Size: 2 MB

Access Lists:

IPv4: 128

MAC: 128

Layer 3 Features

DHCP Server (Local Networks): ✓

DHCP Relay: ✓

Inter-VLAN Routing (Local Networks): ✓

Static Routing (Local Networks): ✓

LACP Port Aggregation: ✓

STP RSTP: ✓

QoS (DSCP): ✓

Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron): ✓

Advanced IGMP Configuration (Querier, Fast Leave, Router Port): ✓

IGMP Snooping: ✓

802.1X Control: ✓

MAC-Based ACLs Device Isolation: ✓

DHCP Snooping Guarding: ✓

Egress Rate Limit: ✓

Flow Control: ✓

Storm Control: ✓

Multicast Broadcast Rate Limiting: ✓

MAC Address Blocking: ✓

IP-Based ACLs Network Isolation: ✓

MAC-Based Port Restriction: ✓

Port Isolation: ✓

Port Mirroring: ✓

Jumbo Frames: ✓

LLDP-MED: ✓

Voice VLAN: ✓

Loop Protection: ✓

Hardware

PoE Ports:

PoE+++: 10

Max. PoE Wattage per Port by PSE:

PoE: 15.4W

PoE+: 30W

PoE++: 60W

PoE+++: 90W

Max. Power Consumption:

65W (Excluding PoE output)

520W (Including PoE output)

Power Method:

(1) Universal input, 100—240V AC, 50/60 Hz

(1) USP RPS DC input

Power Input Method: AC input

Power Supply: AC/DC, internal, 550W

Supported Voltage Range: 100—240V AC

Management:

Ethernet

AR

Weight:

Without mounting brackets: 4.6 kg (10.14 lb)

With mounting brackets: 4.7 kg (10.36 lb)

Enclosure Material: SGCC steel

Mount Material: SGCC steel

Supported Rack Depth: 400~1200 mm (15.7-47.2'')

LCM Display: 1.3' touchscreen

ESD Protection: Air: ± 30kV, contact: ± 30kV

Ambient Operating Temperature: -5 to 40° C (23 to 104° F)

Ambient Operating Humidity: 10 to 90% noncondensing

Etherlighting™:

Ethernet: ✓

SFP+: ✓

LEDs:

RPS: ✓

System: ✓

NDAA Compliant: ✓

Certifications: CE, FCC, IC

Application Requirements:

UniFi Network: Version 9.1.120 and later
