With features of simple installation, easy operation, and high performance-cost ratio, Dahua Entry series network camera is applicable to small and medium-sized scenes, such as homes / residences, small-sized retail stores, and other small and medium-sized enterprises.
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.
Motion Detection
When moving objects appear in the monitoring image, Dahua Motion Detection (General) technology triggers alarm or records.
Smart Illumination
Dahua Smart Illumination technology can display image in the environment of low illuminance or completely dark environment. According to the distance of the targets, the camera adjusts
Illuminations intensity automatically to display the details of the moving target.
Cyber Security
Dahua network camera is equipped with a series of key security technologies, such as security authentication and authorization, access control, trusted protection, encrypted transmission, and encrypted storage, which improve its security defense and data protection, and prevent malicious programs from invading the device.
Protection (IP67,wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
| Adjustment shutter speed | Auto/Manual |
| Angle of rotation | 360 ° |
| Auto pan mode | Yes |
| Back Light Compensation (BLC) | Yes |
| Bit rate | H.264: 32 kbps-6144 kbps, H.265: 12 kbps-6144 kbps |
| Bit rate control | Constant Bit Rate (CBR),Variable Bit Rate (VBR) |
| Bluetooth | No |
| Built-in HDD | No |
| Camera pan control | Yes |
| Camera shutter speed | 1/3 s-1/100,000 s |
| Camera tilt control | Yes |
| Card reader integrated | Yes |
| Certification | CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B |
| Closest focusing distance | 1.2 m |
| Compatible memory cards | MicroSD (TransFlash) |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| DC output voltage | 12 |
| Detect distance (tele) | 131 m |
| Detect distance (wide) | 48 m |
| Diameter | 90.4 mm |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Focal length range | 2.8 - 12 mm |
| Focus | Motorized/Manual |
| Form factor | Bullet |
| Frame rate | 30 fps |
| Gain control type | Auto/Manual |
| Height | 244.1 mm |
| Highlight Compensation (HLC) | Yes |
| Identify distance | 13 m |
| Identify distance (tele) | 13 m |
| Identify distance (wide) | 5 m |
| Internal memory | 128 MB |
| International Protection (IP) code | IP67 |
| LED type | IR |
| Maximum memory card size | 256 GB |
| Maximum operating distance | 50 m |
| Maximum resolution | 1920 x 1080 pixels |
| Minimum illumination | 0.0005 lx |
| Mounting type | Ceiling/Wall/Pole |
| Night vision | Yes |
| Night vision distance | 50 m |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Normal focusing range | 1.2 m |
| Number of cameras | 1 |
| Number of illumination LEDs | 2 |
| Number of lenses | 1 |
| Number of users | 6 user(s) |
| Observe distance (tele) | 52 m |
| Observe distance (wide) | 19 m |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -30 - 60 °C |
| Optical sensor size | 1/2.8 " |
| Package weight | 1120 g |
| Pan range | 0 - 360 ° |
| Placement supported | Outdoor |
| Power consumption (max) | 4.3 W |
| Power consumption (Power over Ethernet (PoE)) | 5.5 W |
| Power consumption (typical) | 1.8 W |
| Power source type | DC,PoE |
| Privacy masking | Yes |
| Product colour | Black/White |
| Recognize distance (tele) | 26 m |
| Recognize distance (wide) | 10 m |
| Region of Interest (ROI) encoding | Yes |
| ROM capacity | 16 MB |
| Sensor type | CMOS |
| Smart IR | Yes |
| Summary | Dahua Technology Entry IPC-HFW1230T-ZS-S5. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: Black, White, Form factor: Bullet. Minimum illumination: 0.0005 lx, Angle of rotation: 360°, Tilt angle range: 0 - 90°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Focal length range: 2.8 - 12, Focus: Motorized/Manual, Identify distance: 13 m |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576 |
| Supported network protocols | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast; DDNS |
| Supported video modes | 1080p/720p |
| Tilt angle range | 0 - 90 ° |
| Total megapixels | 2 MP |
| Type | IP security camera |
| Unit Box Height | 0.16 |
| Unit Box Length | 0.31 |
| Unit Box Width | 0.145 |
| Unit Calculated Volume | 0.007192 cubm |
| Unit Calculated Weight | 1.08 kg |
| Units per Shipping Box | 1 |
| Vendor Homepage | https://www.dahuasecurity.com/mena/products/All-Products/Network-Cameras/Entry-Series/2MP/IPC-HFW1230T-ZS-S5 |
| Video compression formats | H.264/H.264+/H.265/H.265+ |
| Video streaming | Yes |
| Weight | 860 g |
| White balance | Auto |
| Wi-Fi | No |
| Wide Dynamic Range (WDR) | Yes |
