TELTONIKA industrial Ethernet to 4G LTE IoT gateway

Industrial LTE Cat 4 Gateway Board TRB140 is equipped with a single Ethernet port, Digital Inputs/Outputs and micro-USB port. TRB140 compact design makes this Gateway perfect for an application where a sole gadget must be granted reliable Internet connectivity. TRB140 is engineered to be used in an Industrial application therefore it has a wide range of software features such as SMS control, Firewall, Open VPN, IPsec, RMS and FOTA support.

Learn more on the wiki page

Hardware:• Mobile: LTE(Cat4)/3G/2G; • SIM slot: Mini SIM (2FF); • Antenna connector: 1 x SMA for LTE; • Ethernet: 1 x 10/100/1000 Mbps; • Input/Output: 2 x Digital Input/Output (configurable); • CPU: ARM Cortex-A7 1.2 GHz CPU; • RAM: 128 MB (50 MB available for user space); • Flash: 512 MB (70 MB available for user space); • Input voltage range: 9 - 30 VDC; • Power connector: 4 pin industrial DC power socket; • Configuration interface: Virtual NIC via Micro-USB connector; • LED Indicators: Power, signal, network and data status LEDs.

Software:• Operating System: Linux OS with Yocto SDK (offering high software customization); • Network: NAT, Static/Dynamic routing, Firewall (port forward, traffic rules, custom rules), OpenVPN, DDNS (> 25 service providers supported); • Remote management: RMS Support, FOTA support, SSH, CLI, SMS Utilities (status/configuration); • Status watchdogs: Ping reboot, periodic reboot; • Additional features: Internet connectivity over USB virtual network interface.

Mechanical Environmental:• Operating temperature: -40° C to 75° C; • Storage temperature: -45° C to 80° C; • Operating humidity: 10% to 90% non-condensing; • Storage humidity: 5% to 95% non-condensing; • Dimensions: 60 mm x 70 mm x 18 mm; • Weight: 35.8 g.

Standard package contains:• TRB140 board; • Euro PSU; • 1 x LTE antenna (magnetic mount, SMA male, 3 m cable); • Micro-USB cable (0.8 m); • LAN cable; • QSG (Quick Start Guide); • Packaging box.
