TELTONIKA Industrial 4G Cat 4 Modem

The TRM200 is an industrial-grade LTE Cat 4 modem that delivers reliable 4G connectivity with full backward compatibility to support 3G and 2G networks, ensuring smooth operation in a variety of environments. With a micro USB connector and external antenna, this rugged modem is a cost-effective solution for providing LTE connectivity to industrial equipment.

MobileMobile module: 4G - Cat 4 up to 75 DL/50 UL Mbps, 3G - Up to 42 DL/5.76 UL Mbps, 2G - Up to 236.8 DL/ 236.8 UL kbps 3GPP Release: Release 9

PowerConnector: microUSB Input voltage range: 5V - powered via microUSB Power consumption: Idle: < 0.9 W, Max: < 3.2 W

Physical InterfacesStatus LEDs: 1 x Power LED, 1 x Network LED, 1 x Mobile LED SIM: 1 x SIM slot (Mini SIM - 2FF), 1.8 V/3 V Power: 1x microUSB Antennas: 1 x SMA for Mobile

Physical SpecificationCasing material: Aluminum housing Dimensions (W x H x D): 74.5 x 25 x 64.5 mm Weight: 274 g Mounting options: DIN rail, wall mount, flat surface (all require additional kit)

Operating EnvironmentOperating temperature: -40 °C to 75 °C Operating humidity: 10% to 90% non-condensing Ingress Protection Rating: IP30

TRM SoftwareTRM SOFTWARE USB Driver RUT#03: Windows 7/8/8.1/10, Linux 2.6 or later, Android 2.3/4.0/4.2/4.4/5.0/5.1/6.0/7.0 NDIS Driver: Windows 7/8/8.1/10

Regulatory Type ApprovalsRegulatory: CE, UKCA, CB, EAC, UCRF, WEEE

Standard package:

• TRM200


• 1x Mobile antenna (swivel, SMA male)


• Micro USB cable (0.8 m)


• 1x hex key


• QSG (Quick Start Guide)


• Packaging box
