TP-LINK Omada Cloud Controller

Professional Centralized Management for Wi-Fi Network

Dedicated In Network Centralized Management

The OC200 Omada Cloud Controller is designed to provide centralized management for the entire Omada network. Monitor statistics in real-time, view a graphical analysis of network traffic, create a captive portal, upgrade and reboot your system, and easily scale your network to boost your business.

• No PC/Server required


• Reliability and Security


• Cloud Access for ultra convenience

HARDWARE FEATURES

Interface:2 x 10/100Mbps Ethernet Port 1 x USB 2.0 Port for configuration backup 1 x Micro USB Port for power

Power Supply: 802.3af/at PoE or Micro USB（DC 5V/Minimum 1A） Power Consumption: 5 W Dimensions: 3.9×3.9×1.0 inch. (100×98×25mm)

FEATURES

Management Scale: 100 EAPs

Wireless Function: L3 Management Multi-SSID: Load Balance Band Steering Airtime Fairness Beamforming Rate Limit Wireless Schedule QoS

Wireless Security: WEP/WPA-PSK/WPA2-PSK/WPA/WPA2 Encryption Access Control SSID to VLAN Mapping Guest Network

AP Management: Support Omada EAP Series Cloud Access Omada App Support Reboot Wireless Schedule Auto Backup Restore Batch Firmware Upgrade

Authentication: Captive Portal

OTHERS

Certification: CE, FCC, RoHS

Package Contents: Omada Cloud Controller OC200 Quick Installation Guide Ethernet Cable

System Requirements: Microsoft® Windows®10, 8, 7, Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux

Environment: Operating Temperature: 0 ~40 (32 ~104 ) Storage Temperature: -40 ~70 (-40 ~158 ) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
