TP-LINK 8-Port Gigabit Desktop Switch

• 8 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX


• Green Ethernet technology saves the power up to 80%


• IEEE 802.3x flow control provides reliable data transfer


• Plastic case, desktop or wall-mounting design


• Plug and play, no configuration required

HARDWARE FEATURESStandards and Protocols: IEEE 802.3i/802.3u/ 802.3ab/802.3x Interface: 8 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX Fan Quantity: Fanless Physical Security Lock: No External Power Supply: External Power Adapter (Output: 9VDC/0.6A) Jumbo Frame: 15 KB Switching Capacity: 16 Gbps Dimensions ( W x D x H ): 7.1 * 3.5 * 1.0 in. (180 * 90 * 25.5 mm) Max Power Consumption: 4.63W(220V/50Hz) Max Heat Dissipation: 15.80BTU/h

SOFTWARE FEATURESTransfer Method: Store and Forward MAC Address Table: 4K Advanced Functions: Green Technology 802.3X Flow Control Back Pressure 802.1p/DSCP QoS (for V7 and later version)

OTHERSCertification: FCC, CE, RoHs Package Contents: 8-Port Gigabit Desktop Switch TL-SG1008D Power Adapter Installation Guide Environment: Operating Temperature: 0 ~40 (32 ~104 ) Storage Temperature: -40 ~70 (-40 ~158 ) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
