Switch, TP-LINK, LS1210GP, PoE+ ports 8, LS1210GP
Product reference: 2-4895252504569

Switch, TP-LINK, LS1210GP, PoE+ ports 8, LS1210GP

Product reference: 2-4895252504569
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
54,64 €
Last product in warehouse

Guarantee
36 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Overview
The TP-Link LiteWave Series PoE Switches require no configuration and provide PoE (Power over Ethernet) ports. They can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

  • Full Gigabit Ports: 9× gigabit auto-negotiation RJ45 Ethernet ports and 1× gigabit SFP port provide up to 20 Gbps switching capacity
  • 61 W PoE Budget: Eight gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
  • Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
  • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
  • Traffic Separation for Higher Security: Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storm
  • Plug and Play: Simply plug and play for instant connectivity with no configuration required
  • Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses
  • Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments

10G support No
AC input frequency 50 Hz
AC input voltage 220 V
Auto MDI/MDI-X Yes
Auto-negotiation Yes
Basic switching RJ-45 Ethernet ports quantity 9
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Cable types supported Cat3/Cat4/Cat5/Cat5e
Certification CE, FCC, RoHS
DC input voltage 53.5 V
Depth 126 mm
Flow control support Yes
Forwarding rate 14.88 Mpps
Heat dissipation 261.66 BTU/h
Height 26 mm
Jumbo frames 16000
LED indicators Yes
MAC address table 4000 entries
Model name LS1210GP
Networking standards IEEE 802.1p/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
Operating relative humidity (H-H) 10 - 90 %
Operating temperature (T-T) 0 - 40 °C
Package type Box
Power consumption (max) 76.96 W
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 8
Power over Ethernet (PoE) power per port 30 W
Power source DC/PoE
Power supply included Yes
Product colour Black
Product Net Weight 1 kg
Quality of Service (QoS) support Yes
SFP module slots quantity 1
Shipping Box Depth 32 cm
Shipping Box Height 24 cm
Shipping Box Weight 1.2 kg
Shipping Box Width 7 cm
Storage relative humidity (H-H) 5 - 90 %
Storage temperature (T-T) -40 - 70 °C
Store-and-forward Yes
Summary TP-Link LiteWave 10-Port Gigabit Desktop Switch with 8-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 9. MAC address table: 4000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE.... DC input voltage: 53.5 V. Power over Ethernet (PoE)
Switch type Unmanaged
Switching capacity 20 Gbit/s
Total Power over Ethernet (PoE) budget 61 W
Unit Box Height 0.24
Unit Box Length 0.32
Unit Box Width 0.07
Unit Calculated Volume 0.005376 cubm
Unit Calculated Weight 1.2 kg
Unit Depth 32 cm
Unit Height 24 cm
Unit Width 7 cm
Units per Shipping Box 1
User guide Yes
Vendor Homepage https://www.tp-link.com/uk/business-networking/soho-switch-poe/ls1210gp/
Width 209 mm
