Switch, TP-LINK, 8x10Base-T / 100Base-TX, TL-SF1008D
Product reference:
2-6935364020071
Switch, TP-LINK, 8x10Base-T / 100Base-TX, TL-SF1008D
Product reference:
2-6935364020071
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
Not available
What This Product Does
The TL-SF1008D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 8 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1008D can save power consumption, making it an eco-friendly solution for your business network.
High Performance
TL-SF1008D Fast Ethernet Switch provides 8 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1008D forwards and filters packets at full wire-speed for maximum throughput. With 2K Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1008D work reliably.
TP-Link Green Technology
This new generation TL-SF1008D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled.
Easy to Use
The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.
- 8x 10/100Mbps auto-negotiation RJ45 ports, supports auto MDI/MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Plastic case, desktop design
- Plug and play, no configuration required
| 10G support | No |
| AC adapter included | Yes |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Compliance certificates | CE/Federal Communications Commission (FCC)/RoHS |
| Copper ethernet cabling technology | 100BASE-TX/10BASE-T |
| DC input voltage | 5 V |
| Depth | 79 mm |
| Fanless | Yes |
| Fast Ethernet (copper) ports quantity | 8 |
| Flow control support | Yes |
| Full duplex | Yes |
| Half duplex | Yes |
| Harmonized System (HS) code | 85176990 |
| Heat dissipation | 6.99 BTU/h |
| Height | 22.5 mm |
| Input current | 0.6 A |
| LED indicators | Yes |
| MAC address table | 1000 entries |
| Model name | TL-SF1008D |
| Networking standards | IEEE 802.3/IEEE 802.3ab/IEEE 802.3x |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Package depth | 139 mm |
| Package height | 85 mm |
| Package type | Box |
| Package weight | 357 g |
| Package width | 100 mm |
| Packet buffer memory | 0.768 MB |
| Power connector | DC-in jack |
| Power consumption (max) | 2.05 W |
| Power over Ethernet (PoE) | No |
| Power source | DC |
| Power supply included | No |
| Product colour | White |
| Product Net Weight | 0.13 kg |
| Rack mounting | No |
| Shipping Box Depth | 59 cm |
| Shipping Box Height | 45 cm |
| Shipping Box Weight | 15.8 kg |
| Shipping Box Width | 33 cm |
| Stackable | No |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Store-and-forward | Yes |
| Summary | TP-Link TL-SF1008D. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 1000 entries, Switching capacity: 1.6 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3x. DC input voltage: 5 V. Power connector: DC-in jack |
| Supported network protocols | CSMA/CD, TCP/IP |
| Sustainability compliance | Yes |
| Switch type | Unmanaged |
| Switching capacity | 1.6 Gbit/s |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.14 |
| Unit Box Width | 0.085 |
| Unit Calculated Volume | 0.00146 cubm |
| Unit Calculated Weight | 0.263 kg |
| Unit Depth | 14 cm |
| Unit Height | 10 cm |
| Unit Width | 8.5 cm |
| Units per Shipping Box | 60 |
| User guide | Yes |
| Vendor Homepage | https://www.tp-link.com/us/home-networking/8-port-switch/tl-sf1008d/ |
| Width | 134.5 mm |
