Digitus DN-80115-1 network switch

Digitus 10" Gigabit Ethernet Switch, 16-Port, Unmanaged. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power connector: AC-in jack. Rack mounting, Form factor: 1U

Quickly and cost-effectively expands networks with 16 Gigabit ports—ideal for compact 10-inch distribution solutions.

- 16 × 10/100/1000Base-T RJ45 ports
- 32 Gbps non-blocking switching capacity
- Forwarding rate: up to 1,488 Mpps per port
- Fanless metal enclosure for 24/7 operation
- Plug-and-Play - no configuration required
- Auto-Negotiation & Auto-MDI/MDI-X
- Full compatibility with IEEE 802.3, 802.3u, 802.3ab, and 802.3x
- IEEE 802.3x Flow Control
- 8K MAC Address Table
- Low power consumption (max. 15 W)
- Designed specifically for 10" enclosures (1U)
- Sturdy metal housing for long-lasting use

The DIGITUS® DN-80115-1 packs 16 Gigabit ports into a compact 10-inch footprint, making it ideal for networks with many wired devices. With 32 Gbps switching capacity, it offers sufficient headroom for parallel data transfers even under heavy load. As an unmanaged Layer 2 switch, it is ready for use without configuration: Auto-negotiation and Auto-MDI/MDI-X automatically detect speed, duplex mode, and cable type. The non-blocking store-and-forward architecture with IEEE 802.3x flow control ensures stable, packet-verified forwarding. The fanless metal housing ensures silent continuous operation and is ideal for 10-inch distribution cabinets, wall-mounted distribution units, and structured building cabling.

Management features

Switch type: Unmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 16
Power connector: AC-in jack

Network

Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Feature: Full duplex
Feature: Half duplex
Feature: Auto MDI/MDI-X
Ethernet LAN data rates: 10,100,1000 Mbit/s

Data transmission

Switching capacity: 32 Gbit/s
Forwarding rate: 1488 Mpps
MAC address table: 8000 entries
Feature: Store-and-forward

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Grey
Housing material: Metal
LED indicators: Yes

Performance

Feature: Fanless

Power

Power source: AC
Feature: Power supply included
Power supply location: Internal
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 15 W

Other features

Ethernet interface type: Gigabit Ethernet

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 250 mm
Depth: 150 mm
Height: 42 mm

Packaging content

Cables included: AC
Feature: Quick start guide

Packaging data

Package type: Box
Package width: 240 mm
Package depth: 67 mm
Package height: 320 mm
Package volume: 5145.6 cm³
Package weight: 1.6 kg

Technical details

Products per shipping (inner) case: 1 pc(s)
Shipping (inner) case gross weight: 1.6 kg

Logistics data

UK Trade Tariff code: 85176200
Country of origin: China
Master (outer) case width: 345 mm
Master (outer) case length: 330 mm
Master (outer) case height: 490 mm
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 12.8 kg
Products per master (outer) case: 8 pc(s)
