„Digitus DN-80115-1“ tinklo komutatorius

Digitus 10" Gigabit Ethernet Switch, 16-Port, Unmanaged. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power connector: AC-in jack. Rack mounting, Form factor: 1U

Expands networks quickly and cost-effectively by 16 Gigabit ports, ideal for compact 10" distribution solutions.

- 16 × 10/100/1000Base-T RJ45 ports
- Simple plug & play installation
- 10" rack mounting (25 cm)
- Switching capacity: 32 Gbps
- Forwarding rate: up to 1,488 Mpps per port
- Store-and-forward switching
- Non-blocking architecture
- IEEE 802.3x Flow Control
- Auto-negotiation
- Auto MDI/MDI-X on all ports
- 8K MAC address table
- Fanless metal housing
- Power consumption: max. 15 W

The DIGITUS® DN-80115-1 is a compact 16-port Gigabit switch for high-performance network infrastructures with many wired end devices. With 16 × 10/100/1000Base-T ports and a switching capacity of 32 Gbps, the device offers sufficient performance reserves for parallel data transmissions at high utilization rates. The switch operates as an unmanaged Layer 2 device and requires no configuration. Auto-negotiation automatically detects speed and duplex mode, while Auto MDI/MDI-X enables the use of different cable types without manual adjustment. The non-blocking architecture combined with store-and-forward technology ensures reliable, packet-checked data forwarding. IEEE 802.3x Flow Control (Full Duplex) and Back-Pressure (Half Duplex) support stable performance even with increased network load. The fanless metal housing ensures silent operation and reduces mechanical wear parts. Thanks to its 10" compatibility (1U), the switch is particularly suitable for compact network cabinets, wall distributors or structured building cabling.

Management features

Switch type: Unmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 16
Power connector: AC-in jack

Network

Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Feature: Full duplex
Feature: Half duplex
Feature: Auto MDI/MDI-X
Ethernet LAN data rates: 10,100,1000 Mbit/s

Data transmission

Switching capacity: 32 Gbit/s
Forwarding rate: 1488 Mpps
MAC address table: 8000 entries
Feature: Store-and-forward

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Grey
Housing material: Metal
LED indicators: Yes

Performance

Feature: Fanless

Power

Power source: AC
Feature: Power supply included
Power supply location: Internal
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 15 W

Other features

Ethernet interface type: Gigabit Ethernet

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 250 mm
Depth: 150 mm
Height: 42 mm

Packaging content

Cables included: AC
Feature: Quick start guide

Packaging data

Package type: Box
Package width: 320 mm
Package depth: 240 mm
Package height: 37 mm
Package volume: 5145.6 cm³
Package weight: 1.44 kg

Technical details

Products per shipping (inner) case: 1 pc(s)
Shipping (inner) case gross weight: 1.6 kg

Logistics data

Country of origin: China
Master (outer) case width: 345 mm
Master (outer) case length: 330 mm
Master (outer) case height: 490 mm
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 12.8 kg
Products per master (outer) case: 8 pc(s)
