UBIQUITI Ethernet Surge Protection Outdoor (UACC-ETH-SP-Pro)

ESD protection for outdoor high-speed networks.

- Protects outdoor Ethernet devices, up to 20kA discharge current.

- (2) Passive, surge-protected RJ45 connections

- Quick and easy installation

- Compatible with 10 GbE networks

Mechanical

Dimensions: 91 x 61 x 32.5 mm (3.6 x 2.4 x 1.3')

Weight: 95 g (3.35 oz)

Enclosure Material: Polycarbonate

Weatherproofing: IPX5

Hardware

Networking Interface: (2) RJ45 female connectors

DC Spark-Over Voltage: 90V @ 100V/s

Max. Impulse Spark-Over Voltage: 600V @ 1kV/µs

Discharge Current: 20kA

Insulation: Max. Resistance: 1G ohm @ 50V

Max. Capacitance: 1.0 pF @ 1 MHz

Data Line Protection: Up to 10 Gbps

PoE Support: ✓

ESD/EMP Protection: Absorbing transient current with response to surge voltage from 100V/s to 1kV/µs

Ambient Operating Temperature: -30 to 65° C (-22 to 149° F)

Ambient Operating Humidity: 10 to 90% noncondensing

Shock and Vibration Certification: ETSI300-019-1.4 Standard
