Xiaomi Mi Router AX3000T White EU DVB4423GL

Specifications:

Dimensions:

• 225mm × 172mm × 208.8mm

Hardware Configuration:

• 2.4G Wi-Fi: 2×2 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate is 574Mbps)


• 5GHz Wi-Fi: 2×2 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate is 2402Mbps)


• Antennas: 4 × High gain antennas


• Heat Dissipation: Natural heat dissipation


• Total Ports: 4 × 10/100/1000Mbps self-adaptive WAN/LAN port (Auto MDI/MDIX)


• ED Indicator Light: Single light


• System Reset Button: × 1


• Mesh Networking Button: × 1


• Power Input Port: × 1

Protocol Standards:

• IEEE 802.11a/b/g/n/ac/ax, IEEE 802.3/3u/3ab

Wireless Specifications:

• Dual-band: 2.4GHz, 5GHz


• Modulation:




  • 11b: DSSS: DBPSK (1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps)


  • 11a/g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM (24/36Mbps), 64QAM (48/54Mbps)


  • 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. Data rate: MCS0-MCS15


  • 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM


  • 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM


  • Data rates: MCS0-MCS11 (supports 2 streams)







Software Specifications:

• Operating System: MiWiFi ROM


• Wi-Fi Encryption: WPA-PSK/WPA2-PSK/WPA3-SAE encryption, Wireless access control (black and white list), SSID hidden


• Management Applications: Supports Web, Xiaomi Home App (Android, iOS)



Working Environment:

• Working Environment Temperature: 0 ~ 40°C


• Operating Humidity: 10% ~ 90% RH (non-condensing)


• Storage Temperature: -40 ~ 70


• Storage Humidity: 5% ~ 90% RH (non-condensing)

Package Contents:

• Xiaomi Router AX3000T × 1


• Network Cable × 1


• Power Adaptor × 1


• Warranty Card × 1


• User Manual × 1
