It's time to supercharge your home network with the Generation 6 wireless network and our latest addition to the beloved hAP series. hAP ax² has everything you might need in a primary home access point - and more! Forget endless reviews and comparisons - this is the perfect device for 99% of homes.
Wireless signal is now stronger than ever. Here are the two main ingredients of hAP ax's success: a state-of-the-art dual-band, dual-chain 4-4.5 dBi radio, and the 802.11ax standard with Wave2 support. Let's compare it to the previous generation: depending on your overall setup, that means up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum!
Some might ask - why do we even need higher wireless speeds? Well, countless use cases have been previously impossible or difficult to pull off. For example, working with large media files over the wireless network - without the need to download and upload everything. Do you really have the time to wait? Grab a hAP ax² and save more time for the essential things in life!
The modern quad-core CPU running at 864 MHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with the most advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you're safer than ever before.
Like the previous models, hAP ax² can be mounted vertically, horizontally, or even on the wall - without sacrificing the strong signal.
With so many products and features on the market, even an experienced user can become confused. So it's time for a simple truth for a simple choice: you can't go wrong with a hAP ax² in most homes.
| Antenos stiprinimo lygis (max) | 4 dBi |
| Atitikties sertifikatai | RoHS |
| Atstatymo mygtukas | Taip |
| Aukštis | 37 mm |
| Bruto svoris | 0.535 kg |
| Darbo temperatūros diapazonas (TT) | -40 - 50 °C |
| DC įėjimo lizdas | Taip |
| Energijos suvartojimas | 12 W |
| Eterneto LAN duomenų perdavimo norma | 10/100/1000 Mbit/ai |
| Eterneto LAN sąsajos tipas | Gigabitinis eternetas |
| Eterneto WAN | Taip |
| Ethernet LAN (RJ-45) portų kiekis | 5 |
| Ethernet LAN jungtis | Taip |
| Flash atmintis | 128 MB |
| Gaminio tipas | Stalinis maršrutizatorius |
| Ilgis | 101 mm |
| Integruotas procesorius | Taip |
| Išorinio maitinimo adapteris | Taip |
| Išėjimo srovė | 0.6 A |
| Išėjimo įtampa | 12 - 28 V |
| Kabelių technologija | 10/100/1000Base-T(X) |
| Kintamosios srovės adapteris | Taip |
| LED indikatoriai | Taip |
| Maitinimas per Eternetą (PoE) | Taip |
| Maitinimo šaltinio tipas | DC,PoE |
| Model | C52iG-5HaxD2HaxD-TC |
| Model name | hAP ax2 |
| Neto svoris | 0.3 kg |
| Numatyta operacinė sistema | RouterOS |
| Plotis | 120 mm |
| Pridėti sraigtai | Taip |
| Procesoriaus branduoliai | 4 |
| Procesoriaus dažnis | 864 MHz |
| Produkto spalva | Juoda |
| Sertifikavimas | CE, FCC, IC, EAC |
| Shipping Box Depth | 50.5 cm |
| Shipping Box Height | 22.5 cm |
| Shipping Box Weight | 10.7 kg |
| Shipping Box Width | 27 cm |
| Summary | Mikrotik hAP ax2. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 1200 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Product type: Tabletop router, Product colour: Black. Compliance certificates: RoHS, Certification: CE, FCC, IC, EAC |
| Tinklo standartai | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n |
| Unit Box Height | 0.125 |
| Unit Box Length | 0.19 |
| Unit Box Width | 0.05 |
| Unit Brutto Volume | 0.001534 cubm |
| Vendor Homepage | https://mikrotik.com/product/hap_ax2#fndtn-specifications |
| Vidinė atmintis | 1000 MB |
| Vidutinis laikas tarp trikčių (MTBF) | 100000 h |
| Vieneto aukštis | 12.5 cm |
| Vieneto gylis | 19 cm |
| Vieneto plotis | 5 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 20 |
| WAN tinklo prisijungimo tipas | RJ-45 |
| Wi-Fi standartai | 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax) |
| WLAN duomenų perdavimo sparta (antroji juosta) | 1200 Mbit/ai |
| WLAN duomenų perdavimo sparta (maks.) | 1200 Mbit/ai |
| WLAN duomenų perdavimo sparta (pirmoji juosta) | 574 Mbit/ai |
| "Wi-Fi" dažnių juosta | Dviguba juosta (2,4 GHz / 5 GHz) |
| "Wi-Fi" standartas | Wi-Fi 6 (802.11ax) |
