UBIQUITI UniFi WiFi 7 Outdoor Access Point U7 Pro Outdoor

All-weather IP67 WiFi 7 AP with 6 spatial streams, extended-range AFC 6 GHz support, integrated directional super antenna, and articulation mounting bracket.

Dimensions: Without mount: 170 x 208 x 66.5 mm (6.7 x 8.2 x 2.6') With mount: 170 x 208 x 121.8 mm (6.7 x 8.2 x 4.8') WiFi Standard: WiFi 7 Spatial Streams: 6 Coverage Area: 465 m² (5,000 ft²) Max. Client Count: 300+ Uplink: 2.5 GbE Mounting: Wall Pole (Mounts Included) Weatherproofing: IPX6 IP67 (With cable-gland door kit) Power Method: PoE+

Performance

MIMO: 6 GHz: 2 x 2 (DL/UL MU-MIMO) 5 GHz: 2 x 2 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) Max. Data Rate: 6 GHz: 5.7 Gbps (BW320) 5 GHz: 4.3 Gbps (BW240) 2.4 GHz: 688 Mbps (BW40) Antenna Gain: 6 GHz: Directional internal: 10 dBi 5 GHz: Directional internal: 11 dBi External omni: 8 dBi 2.4 GHz: Directional internal: 8 dBi External omni: 6 dBi Max. TX Power: 6 GHz: 6 dBm 5 GHz: 26 dBm 2.4 GHz: 23 dBm Max. BSSIDs: 8 per Radio Supported Data Rates: 802.11be (WiFi 7): 7.3 Mbps to 8.6 Gbps (MCS0-MCS13 NSS1/2/3/4, EHT 20/40/80/160/240) 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) 802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0-MCS11 NSS1/2/3/4, HE 20/40/80/160) 802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Features

Wireless Meshing: Yes Band Steering: Yes 802.11v BSS Transition Management: Yes 802.11r Fast Roaming: Yes 802.11k Radio Resource Management (RRM): Yes Advanced Radio Management: Yes Passpoint (Hotspot 2.0): Yes Captive Hotspot Portal: Custom Branding Landing Page: Yes Voucher Authentication: Yes Payment-Based Authentication: Yes External Portal Server Support: Yes Password Authentication: Yes Guest Network Isolation: Yes Private Pre-Shared Key (PPSK): Yes WiFi Speed ​​Limiting: Yes Client Device Isolation: Yes WiFi Schedules: Yes RADIUS over TLS (RadSec): Yes Dynamic RADIUS-assigned VLAN: Yes

Hardware

Max. Power Consumption: 21W Supported Voltage Range: 42.5—57V DC Networking Interface: (1) 1/2.5 GbE RJ45 port Weight: Device: 1.2 kg (2.6 lb) With mount: 1.33 kg (2.9 lb) Wind Loading: 74.6 N at 200 km/h (16.8 lbf at 125 mph) Pole Mount Diameter: 1-2.5' (25-63.5 mm) Management: Ethernet Enclosure Material: UV-stabilized polycarbonate, aluminum alloy Mount Material: UV-stabilized polycarbonate LEDs: System: (1) Power: White/Blue (4) Mesh signal: Blue Certifications: FCC, IC NDAA Compliant: Yes Ambient Operating Temperature: -30 to 60° C (-22 to 140° F) Ambient Operating Humidity: 5 to 95% noncondensing

Software

Application Requirements: UniFi Network: Version 9.0.114 and later UniFi OS: iOS™ version 10.20.2 and later Android™ version 10.21.7 and later
