Wall-mounted WiFi 6 access point with a 300-client capacity and a built-in Gigabit, PoE switch.


The UniFi6 In-Wall (U6 IW) is a dual-band, wall-mounted access point with (4) GbE RJ45 ports that brings plug-and-play WiFi 6 to your home or office. One of the U6 IW's ports also supports PoE output so you can connect and power an Ethernet device. With its 2.4 and 5 GHz WiFi 6 bands, the U6 IW offers an aggregate, over-the-air throughput rate of 5.3 Gbps, which can support over 300 clients. The U6 IW is also Bluetooth-compatible so it can be set up in minutes and managed from anywhere via the UniFi Network web application or mobile app.


Features:



  • High-efficiency, four-stream WiFi 6 technology

  • 5 GHz WiFi 6 band (4x4 MU-MIMO and OFDMA)

  • 2.4 GHz WiFi 6 band (2x2 MU-MIMO and OFDMA)

  • (4) GbE RJ45 ports, including one that supports PoE output

  • 300+ client capacity

  • Simple, Bluetooth-powered setup via the UniFi Network web application or mobile app





































































































































































Mechanical
Dimensions139.66 x 96 x 31.19 mm (5.5 x 3.78 x 1.28')
Weight460 g (1.01 lb)
Enclosure materialsPlastic, aluminum
Mounting materialAluminum
Hardware
Processor specsDual-Core® Cortex® A53 at 1 GHz
Memory information1GB
Management interfacesEthernet Bluetooth
Networking interfaces(1) Data-in: 1GbE RJ45 port (4) Data-out: 1GbE RJ45 port
PoE interfaces(1) PoE in (PoE output not used) (1) PoE out (requires a PoE+ switch)
ButtonFactory reset
LED*White/blue*Due to chip supply shortages, the U6 AP's LED has been limited to only white and blue color modes.
Power methodPoE
Power supplyUniFi PoE switch 48V, 0.5A PoE adapter (optional)
Max. power consumptionExcluding PoE output: 13.5W
Max PoE wattage per port by PSE15.4W* *Requires a PoE+ switch
Voltage range PoE mode44 to 57VDC
Max. TX power 2.4 GHz 5 GHz22 dBm 26 dBm
MIMO 2.4GHz 5GHz2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO)
Throughput rate 2.4 GHz 5 GHz573.5 Mbps 4.8 Gbps
Antenna gain 2.4 GHz 5 GHz5 dBi 5.9 dBi
Operating temperature-30 to 60° C (-22 to 140° F)
Operating humidity5 - 95% non-condensing
CertificationsCE, FCC, IC
Software
WiFi standards802.11a/b/g WiFi 4/WiFi 5/WiFi 6
Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID8 on the radio
VLANs802.1Q
Advanced QoSPer-user rate limiting
Guest traffic isolationSupported
Concurrent clients300+
Zero-wait DFSYes
Supported Data Rates
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
