UBIQUITI UniFi Cloud Gateway Industrial

High Density Gateway
The Ubiquiti UniFi Cloud Gateway Industrial is engineered for demanding environments where performance, reliability, and scalability are critical. Designed as a ruggedized and fanless solution, it operates efficiently in challenging conditions while maintaining consistent network performance. With support for over 500 simultaneous users and the ability to manage more than 50 UniFi devices, this gateway is built for high density deployments in industrial, commercial, or large scale enterprise settings. Its architecture is optimized to support advanced UniFi applications, including Network, Protect, Access, Talk, and Connect, all within a single integrated platform. This allows administrators to manage complex infrastructures from a unified interface, simplifying operations and reducing system complexity.
The device also supports a wide range of connected hardware, including high resolution cameras and access control systems, making it a versatile foundation for integrated network environments. Designed for flexible installation, the gateway supports wall mounting, desktop placement with an included stand, or rack mounting with an optional accessory. Its compact yet durable construction, combining polycarbonate and aluminum alloy materials, ensures long term reliability in both controlled and harsh environments. With its combination of industrial grade durability, centralized application support, and high capacity device management, the UniFi Cloud Gateway Industrial delivers a powerful and scalable networking solution for organizations that require dependable performance under demanding conditions.

Intelligent Network Control
The UniFi Cloud Gateway Industrial integrates a comprehensive suite of advanced security and networking technologies designed to protect and optimize modern infrastructures. At its core is a high performance security engine featuring a stateful firewall and application aware Layer 7 filtering, enabling deep inspection and precise control of network traffic based on applications, domains, and user defined rules. The built in intrusion detection and prevention system delivers real time threat monitoring and mitigation, supported by a database of over 55,000 signatures. This provides strong protection against evolving cyber threats without requiring additional licensing. Additional features such as content filtering and ad blocking further enhance network safety and improve user experience.
For secure connectivity across locations, the device supports multiple VPN technologies including WireGuard, OpenVPN, and IPsec. Zero configuration VPN options simplify deployment, while site to site connectivity enables seamless communication between distributed networks. The integrated SD WAN functionality allows intelligent traffic routing and optimization without added complexity. Advanced networking features such as VLAN based segmentation, dynamic routing, and quality of service management ensure efficient traffic handling and network stability. Multi WAN load balancing and failover capabilities further improve reliability, making the gateway suitable for mission critical deployments where uptime and security are essential.

Powerful Hardware
The UniFi Cloud Gateway Industrial is built on a powerful hardware platform designed to support high performance networking and intensive workloads. It features a quad core ARM processor running at 2.2 GHz, combined with 3 GB of system memory, enabling smooth operation across multiple applications and large numbers of connected devices. For connectivity, the device offers a versatile range of high speed interfaces, including 10 GbE and 2.5 GbE ports, as well as a 10G SFP+ uplink. The integrated switch includes multiple PoE capable ports, supporting both PoE+ and PoE+++ standards, allowing direct powering of connected devices such as cameras, access points, and other network equipment.
With a total system power capacity of 350W and a combined PoE budget distributed between DC and ATX inputs, the gateway is capable of supporting high density PoE deployments without the need for additional power infrastructure. This makes it especially suitable for environments where multiple powered devices must be deployed efficiently. The device also includes a pre installed 128 GB microSD card for local storage, with support for expansion via the same slot. This allows storage of application data such as video recordings or logs directly on the gateway. Combined with its fanless cooling design and wide operating temperature range, the UniFi Cloud Gateway Industrial delivers reliable performance in even the most demanding conditions.

Dimensions: Device: 307.9 x 203.5 x 43.7 mm (12.1 x 8 x 1.7") Table stand: 203.5 x 100.2 x 21.9 mm (8 x 3.9 x 0.9")
UniFi Application Suite:
Network: ✓
Protect: ✓
Access: ✓
Talk: ✓
Connect: ✓
Managed UniFi Devices: 50+
Managed Cameras:
(15) HD
(8) 2K
(5) 4K
Managed Access Hubs: 50
Simultaneous Users Connected: 500+
Max. WAN Port Count: 5
Default WAN Ports:
(1) 10G SFP+
(1) 10 GbE RJ45
(1) 2.5 GbE RJ45
Port Layout:
2.5 GbE RJ45: 4 (2 PoE+++, 2 PoE+) (2.5G/1G/100M)
10 GbE RJ45: 1 (PoE+++) (10G/5G/2.5G/1G/100M)
10G SFP+: 1 (10G/1G)
IDS/IPS Throughput: 5 Gbps
Form Factor:
Wall-mounted
Compact desktop (Table stand included)
Rack mount (Accessory sold separately)
Coverage Area: 115 m² (1,250 ft²)

Security

Stateful Firewall: ✓
Application-Aware Layer 7 Firewall: ✓
DPI Traffic Identification: ✓
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps): ✓
Content Filtering: ✓
Intrusion Prevention (IPS/IDS): ✓
Ad Blocking: ✓
IDS/IPS Signatures: 55,000+ with CyberSecure
VLAN/Subnet-based Traffic Segmentation: ✓

VPN SD-WAN

License-Free SD-WAN: ✓
Site-to-Site VPN:
Site Magic: ✓
IPsec: ✓
OpenVPN: ✓
VPN Server:
Identity Endpoint One-Click VPN: ✓
Teleport Zero-Configuration VPN: ✓
WireGuard: ✓
OpenVPN: ✓
L2TP: ✓
VPN Client:
OpenVPN: ✓
WireGuard: ✓

Networking

Multi-WAN Load Balancing: ✓
Dynamic Routing:
OSPF: ✓
Advanced QoS: ✓
Multicast DNS (mDNS): ✓
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT): ✓
Integrated RADIUS Server: ✓
RADIUS over TLS (RadSec): ✓
Additional Internet Failover with UniFi LTE Backup: ✓
Internet Quality and Outage Reporting: ✓
MAC Address Table Size: 4,000
Virtual Network Override: ✓

Integrated WiFi

WiFi Standard: 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7)
Throughput:
5 GHz: 4.3 Gbps
2.4 GHz: 688 Mbps
MIMO:
5 GHz: 2 x 2 (DL/UL MU-MIMO)
2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
Antenna Gain:
5 GHz:
Stub antenna: 5 dBi
Terminal (Omni) antenna: 6 dBi
2.4 GHz:
Stub antenna: 3 dBi
Terminal (Omni) antenna: 6 dBi
Max. TX Power:
5 GHz: 26 dBm
2.4 GHz: 23 dBm
Supported Data Rates:
802.11be (WiFi 7): 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Hardware

NVR Storage: Pre-installed 128 GB microSD for NVR
Expansion Slot: MicroSD Card
PoE Budget:
DC input: 270W
ATX power: 75W
Max. PoE Wattage per Port by PSE:
PoE+: 30W
PoE+++: 90W
Voltage Range PoE Mode: 50-57V
Max. Power Consumption: 28W (Excluding PoE output)
Power Method:
(1) DC Input (350W PSU)
(1) ATX power (48V)
Power Supply:
54V DC, 350W (Adapter included)
ATX power (48V)
Supported Voltage Range: 100-240V AC
Heat Dissipation: 95 BTU/hr (Excluding PoE output)
Processor: Quad-core ARM® Cortex®-A73 at 2.2 GHz
System Memory: 3 GB
Weight:
Device: 2.4 kg (5.3 lb)
Table stand: 321 g (11.3 oz)
Enclosure Material:
Device: Polycarbonate, aluminium alloy
Table stand: Polycarbonate, galvanized steel, silicone rubber
Management:
Ethernet
Bluetooth
LEDs:
Ethernet: ✓
SFP+: ✓
System: ✓
MicroSD: ✓
SIM: ✓
Button:
(1) Factory reset
(2) Handle release buttons
ESD/EMP Protection: Air: ± 8kV, contact: ± 4kV
Ambient Operating Temperature: -30 to 50° C (-22 to 122° F)
Ambient Operating Humidity: 5 to 95% noncondensing
NDAA Compliant: ✓
Certifications: CE, FCC, IC

Software

Application Requirements:
Mobile App:
UniFi iOS™: Version 10.32.0 and later
UniFi Android™: Version 10.35.0 and later
