UBIQUITI UDB-Switch, 2.5G PoE switch with Wi-Fi 7 Unifi bridge

High-Speed Switching

The Ubiquiti Device Bridge Switch (UDB-Switch) is a compact yet powerful PoE+ switch designed for modern high-capacity networks that require both wired performance and wireless flexibility. It features one 10 GbE Ethernet port and seven 2.5 GbE ports, enabling fast aggregation of access points, cameras, workstations, and other network devices. What sets the UDB-Switch apart is its integrated WiFi 7 (6 GHz-ready) wireless bridge, allowing it to establish a high-throughput wireless uplink to UniFi WiFi infrastructure without running fiber or Ethernet. With support for wide channel bandwidths up to 320 MHz and data rates of up to 5.8 Gbps on the 6 GHz band, the device delivers low-latency, high-capacity links suitable for demanding enterprise and campus deployments. This combination of multi-gig switching and advanced wireless bridging makes the UDB-Switch an ideal solution for locations where cabling is limited or impractical.

Efficient Power Management

The UDB-Switch is designed to simplify deployments by combining switching, wireless bridging, and power delivery in a single compact device. All eight Ethernet ports support PoE+, providing up to 30 W per port to power UniFi access points, IP cameras, and other PoE-enabled devices. With the included 60 W power adapter, the switch offers a total PoE budget of 35 W, ideal for smaller installations. For more demanding environments, an optional 210 W adapter increases the total PoE availability to an impressive 185 W, supporting multiple high-power devices simultaneously. The switch itself consumes up to 25 W excluding PoE output, ensuring efficient operation. Designed for desktop or wall mounting, the UDB-Switch fits easily into offices, retail spaces, warehouses, or remote network nodes. This scalability allows the same device to be used in small setups today and expanded later as network requirements grow.

Enterprise-Grade Reliability

Built for professional environments, the UDB-Switch integrates seamlessly into the UniFi ecosystem and is managed through the UniFi Network application (version 10.0.156 or later). It supports management over Ethernet or WiFi, includes a built-in 0.96-inch status display for quick diagnostics, and features WPA3-SAE wireless security enabled by default. The internal high-gain antennas (8 dBi on both 5 GHz and 6 GHz) and advanced MIMO support ensure stable wireless performance even in challenging RF conditions. The device operates reliably in temperatures from -30 to +40 °C, making it suitable for indoor and semi-protected environments. NDAA compliance and CE, FCC, and IC certifications allow deployment in corporate, public sector, and regulated installations. Combining compact design, advanced security, and multi-gig performance, the UDB-Switch serves as a dependable building block for modern UniFi networks.

Dimensions: 212.9 x 113 x 32.5 mm (8.4 x 4.4 x 1.3")

WiFi Standard: WiFi 7

Spatial Streams: 4

Mounting Locations: Desktop, wall

Power Method: DC jack (54V DC/1.1A)

Power Supply: 54V DC/1.1A (Adapter included)

Performance

MIMO:

6 GHz: 2 x 2

5 GHz: 2 x 2

Max. Data Rate:

6 GHz: 5.8 Gbps (BW320)

5 GHz: 4.3 Gbps (BW240)

Antenna Gain:

6 GHz: 8 dBi

5 GHz: 8 dBi

Max. TX Power:

6 GHz: 23 dBm

5 GHz: 26 dBm

Max. Conducted TX Power: 26 dBm (Combined)

Supported Data Rates:

802.11be (WiFi 7):

6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)

5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)

802.11ax (WiFi 6):

7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

802.11ac (WiFi 5):

6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

802.11n:

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

802.11a:

6, 9, 12, 18, 24, 36, 48, 54 Mbps

Wireless Security: WPA3 SAE (Always On)

Hardware

Max. Power Consumption: 25W (Excluding PoE output)

Supported Voltage Range: 42.5-57V DC

Networking Interface:

(1) 10 GbE RJ45 port

(7) 2.5 GbE RJ45 ports

PoE Interface: (8) PoE+ ports

Max. PoE Wattage per Port: 30W

Total PoE Availability:

60W AC adapter input: 35W

210W AC adapter input: 185W

Antennas: (1) Internal

Management:

Ethernet

WiFi

Channel Bandwidth: 20/40/80/160/240/320 MHz

Weight:

Device: 548 g (1.21 lb)

With mount: 563 g (1.24 lb)

Enclosure Material: Polycarbonate

Mount Material: Polycarbonate

LCM Display: 0.96" status display

Button: (1) Factory reset

NDAA Compliant: ✓

Certifications: CE, FCC, IC

Operating Frequency: Worldwide: 5150—5875 MHz 5945—7125 MHz

Ambient Operating Temperature: -30 to 40° C (-22 to 104° F)

Ambient Operating Humidity: 5 to 95% noncondensing

Software

Application Requirements:

UniFi Network: Version 10.0.156 or later.
