UBIQUITI PoE+ Injector
Product reference: 18-U-POE-at

UBIQUITI PoE+ Injector

  • −2%
UBIQUITI PoE+ Injector
UBIQUITI PoE+ Injector
UBIQUITI PoE+ Injector
UBIQUITI PoE+ Injector
UBIQUITI PoE+ Injector
UBIQUITI PoE+ Injector

UBIQUITI PoE+ Injector

Product reference: 18-U-POE-at

UBIQUITI PoE+ Injector

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
18,19 €
18,57 €
Product in warehouse

Guarantee
12 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!
Fill in the required fields*
Not available

Compact adapter capable of delivering 30W of PoE+ to the U6 LR, U6 Pro, and other PoE+ devices.


The PoE+ Injector (U PoE AT) is designed to power PoE+ devices. The U PoE AT delivers up to 30W of PoE+ that can be used to power the UniFi6 Long-Range (U6 LR), UniFi6 Pro (U6 Pro), and other devices that adhere to the PoE+ standard. It also provides enhanced protection against electrical surges.


Features:



  • Delivers up to 30W of PoE+

  • Compatible with the U6 LR, U6 Pro, and other PoE+ devices

  • Surge and clamping protection

  • AC cable with earth ground





























































































































ModelU-POE-at
Dimensions93 x 62 x 35mm (3.66 x 2.44 x 1.38')
Weight156g (5.5oz)
Output Voltage48VDC @ 0.65A
LAN Activity IndicatorNo
Gigabit LAN PortYes
Remote Reset CapabilityYes
Reset ButtonNo
Rated Voltage100-240VAC @ 50/60Hz
Input Current0.75A@90VAC
Inrush Current<100A Peak @230VAC, 26
Efficiency87%
Output Ripple1% Max.
Switching Frequency70 kHz Max.
Line Regulation≤ 3%
Load Regulation≤ 5%
2-Pair PoweringPins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering-
Operating Temperature0 to 40°C (32 to 104°F)
Storage Temperature-30 to 70°C (-22 to 158°F)
Operating Humidity35 to 90% Non-condensing
AC ConnectorIEC-320 C6
Data IN / PoERJ45 Shielded Socket
Surge ProtectionDifference and Common Mode
Clamping Protection11V Data, 60V Power
Max. Surge Discharge1500A (8/20μs) Power
Peak Pulse Current36A (10/1000 μs) Date
Shunt Capacitance<5 pF date
Response Time<1ns
CertificationsCE, FCC, IC, UL
