UBIQUITI NanoStation 5AC Loco 13 dBi Outdoor airMAX CPE, Loco5AC

Sleek Industrial Design

The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.

Management Wi-Fi Radio

Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.

Improved Surge Protection

The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.

Now with airOS®8

airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.

Dimensions: 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33') Weight: 180 g (6.35 oz) Power Supply: 24V, 0.5A Gigabit PoE Supply (NOT INCLUDED) Max. Power Consumption: 8.5W Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return) Gain: 13 dBi Networking Interface: 10/100/1000 Mbps Ethernet Port Channel Bandwidths: 10/20/30/40/50/60/80 MHz Processor: Specs Atheros MIPS 74Kc, 560 MHz Memory: 64 MB DDR2 Cross-pol Isolation: 20 dB Minimum Max. VSWR: 1.8:1 Beamwidth: 45° (H-pol) / 45° (V-pol) / 45° (Elevation) Polarization: Dual Linear Enclosure: Outdoor UV Stabilized Plastic LEDs: (1) Power Mounting: Pole-Mount (Kit Included) Operating Temperature: -40 to 70° C (-40 to 158° F) Operating Humidity: 5 to 95% Noncondensing RoHS Compliance: Yes ESD/EMP Protection: ±24kV Contact/Air Shock Vibration: ETSI300-019-1.4 Certifications: CE, FCC, IC

Operating Frequency (MHz): 5150 - 5875 Management Radio (MHz): 2412 - 2472
