UBIQUITI Indoor / outdoor, 4x4 WiFi 6 Access Point WiFi 6 Mesh
Product reference: 18-U6-Mesh

UBIQUITI Indoor/outdoor, 4x4 WiFi 6 Access Point WiFi 6 Mesh

UBIQUITI Indoor / outdoor, 4x4 WiFi 6 Access Point WiFi 6 Mesh

Product reference: 18-U6-Mesh

UBIQUITI Indoor/outdoor, 4x4 WiFi 6 Access Point WiFi 6 Mesh

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
212,27
216,60 €
Product in warehouse

Guarantee
12 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!
Fill in the required fields*

Indoor/outdoor, 4x4 WiFi 6 access point designed for mesh applications.


The Access Point WiFi 6 Mesh (U6 Mesh) is a high-performance, four-stream WiFi 6 access point that provides best-in-class signal meshing to enhance the wireless coverage of home and enterprise networks. The U6 Mesh can reach an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz (2x2 MIMO) bands. This access point also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. The sleek U6 Mesh is discreet enough to stage anywhere in your home or office, but also rugged enough to reliably operate outdoors thanks to its IPX5-rated, waterproof housing. The U6 Mesh is a plug-and-play device designed to easily extend your wireless signal to ensure full, seamless coverage and high-quality WiFi connectivity. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.


Features:



  • High-efficiency 4x4 WiFi 6 (802.11ax)

  • 5 GHz (4x4 MU-MIMO and OFDMA) band with a 4.8 Gbps throughput rate

  • 2.4 GHz (2x2 MIMO) band with a 573.5 throughput rate

  • Operates at full 4x4 MIMO with 160 MHz bandwidth

  • Powered with 802.3af PoE (PoE adapter included)





























































































































































Mechanical
DimensionsØ48.5 x 159.5 mm (Ø1.9 x 6.28')
Weight400g (0.88lb)
Enclosure materialPlastic, aluminum
Mounting materialsPlastic
WeatherproofingIPX5
Hardware
Management interfacesEthernet Bluetooth
Network interface(1) GbE RJ45 port
ButtonFactory reset
LED*White/blue*Due to chip supply shortages, the U6 AP's LED has been limited to only white and blue color modes.
Power method802.3af PoE
Power supplyUniFi PoE switch 48V, 0.32A PoE adapter (included)
Supported voltage range44 to 57VDC
Max. power consumption11.4W
Max. TX power 2.4 GHz 5 GHz22 dBm 26 dBm
MIMO 2.4GHz 5GHz2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO)
Throughput rate 2.4 GHz 5 GHz573.5 Mbps 4.8 Gbps
Antenna gain 2.4 GHz 5 GHz3dBi 5dBi
MountingWall, desktop, pole mount(included) Ceiling mount (optional)
Operating temperature-30 to 60° C (-22 to 140° F)
Operating humidity5 - 95% non-condensing
CertificationsCE, FCC, IC
Software
WiFi standards802.11a/b/g WiFi 4/WiFi 5/WiFi 6
Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID8 on the radio
VLANs802.1Q
Advanced QoSPer-user rate limiting
Guest traffic isolationSupported
Concurrent clients300+
Zero wait DFSYes* *Supported with upcoming firmware versions
Supported Data Rates
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
