The Switch Enterprise XG 24 (USW Enterprise XG 24) is a fully managed, multi-gigabit, Layer 3 switch with (24) 10GbE RJ45 ports and (2) 25G SFP28 ports. The USW Enterprise XG 24 also features a 1.3' LCM color touchscreen that concisely displays key system and connection insights.
Additionally, the USW Enterprise XG 24 offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
| Mechanical | |
|---|---|
| Dimensions | 442 x 44 x 285 mm (17.4 x 1.7 x 11.2') |
| Weight | Without mounting brackets: 4.47 kg (9.85 lb) With mounting brackets: 4.57 kg (11.02 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Network interface | (24) 100/1,000/2,500/5,000/10,000 Mbps RJ45 Ethernet |
| Management interface | Ethernet In-Band |
| SFP28 interface | (2) 25G SFP28 ports**The two SFP28 ports do not support mixed speed at 25 Gbps mode. Once one of the SFP28 ports is configured at 25 Gbps mode, the others will be limited at 25 Gbps too. The SFP28 ports only support mixed speed when all ports are at 1 Gbps or 10 Gbps. |
| Total non-blocking throughput | 290 Gbps |
| Switching capacity | 580 Gbps |
| Forwarding rate | 431.52 Mpps |
| Max. power consumption | 100W |
| Power method | (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A |
| Power supply | AC/DC, internal, 100W |
| Services | SMB Layer 3 GbE switch |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| LCD display | (1) 1.3' LCM color touchscreen Bootup animation: bootup in progress Firmware upgrade icon: firmware upgrading |
| Button | Factory reset |
| Operating temperature | -5 to 40°C (23 to 104°F) |
| Operating humidity | 10 to 95% non-condensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | Link/activity |
| Application Requirements | |
| UniFi Network | Version 6.1.67 and later |
