UBIQUITI Camera G6 Instant

Advanced OpticsThe UVC-G6-INS-W is equipped with a 1/1.8' 8MP CMOS sensor, delivering ultra-high-definition 4K video at 3840 x 2160 resolution. Its fixed focal length lens provides a wide field of view: horizontal 109.9°, vertical 56.7°, and diagonal 134.1°, ensuring comprehensive area coverage. The camera supports a maximum frame rate of 30 FPS, capturing smooth and detailed footage. Advanced image settings include brightness, contrast, sharpness, saturation, white balance, exposure control, 2D and 3D noise reduction, motion-based noise reduction, masking, text overlay, and HDR, allowing for precise image optimization in various lighting conditions. Leveraging AI technology, the G6 Instant camera offers intelligent event detection capabilities, including recognition of people, vehicles, animals, faces, and license plates. This enhances security monitoring by providing accurate and timely alerts. The camera features built-in infrared (IR) LEDs with an automatic IR cut filter, enabling clear night vision up to 6 meters. This ensures reliable surveillance in low-light or complete darkness, maintaining high image quality around the clock. AI-based filtering minimizes false alarms by distinguishing between relevant and irrelevant motion events, while customizable detection zones allow for precise monitoring of critical areas.

Robust Construction and Seamless IntegrationDesigned for outdoor use, the UVC-G6-INS-W boasts an IPX5-rated weatherproof enclosure, protecting it against water ingress. Its IK04 impact resistance rating ensures durability against vandalism. The camera operates reliably in temperatures ranging from -20°C to 40°C and humidity levels up to 90% (non-condensing). It supports dual-band WiFi (802.11 a/b/g/n/ac) and Bluetooth for flexible network connectivity. Power is supplied via a 5V 2A USB adapter (included), with an optional PoE to USB-C adapter available separately. Mounting options include wall installations, with the necessary hardware provided, facilitating versatile deployment scenarios. The G6 Instant integrates seamlessly with the UniFi Protect application suite, offering centralized management and real-time monitoring through web and mobile platforms. It features a 10/100 Mbps Ethernet interface for network connectivity and includes a built-in microphone and speaker for two-way audio communication. The camera's firmware supports advanced features such as HDR imaging and smart detection analytics, enhancing situational awareness. Compliance with NDAA regulations ensures suitability for government and enterprise deployments. The package includes the camera unit, mounting hardware, and installation guide, facilitating straightforward setup and integration into existing security systems.

Dimensions: 81.7 x 50.1 x 57.2 mm (3.2 x 2 x 2.3') IR Night Vision: 6 m (20 ft) Face Recognition: Yes License Plate Recognition: Yes Smart Detections (People, Vehicles, Animals): Yes Resolution: 4K Field of View: H: 109.9°, V: 56.7°, D: 134.1° Audio: Two-way audio Weatherproofing: IPX5 Tamper Resistance: IK04 Mounting: Wall mount accessory (Included) UniFi Application Suite: Protect: Yes

Performance

Networking Interface: 802.11 a/b/g/n/ac WiFi Bluetooth Video: Image Settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR Max. Frame Rate: 30 FPS Resolution: 8MP 3840 x 2160 (16:9) Optics: Sensor: 1/1.8' 8MP Lens: Fixed focal length Night Mode: Built-in IR LED illumination and IR cut filter

Hardware

Max. Power Consumption: 7W Supported Voltage Range: 5V DC, 2A Power Method: 5V, 2A USB power adapter (Included) PoE to USB-C adapter (Not included) Processor: Quad-core Arm® Cortex®-A53 based chip Weight: 180 g (6.3 oz) Enclosure Material: Polycarbonate Mount Material: Polycarbonate Expansion Slot: MicroSD card Button: (1) Factory-reset Cable: Cable Connector Type: USB Type-C to USB Type-C Cable Diameter: 3 mm (0.1') Cable Length: 2 m (6.6 ft) Jacket Material: Thermoplastic elastomer Ambient Operating Temperature: -20 to 40° C (-4 to 104° F) Ambient Operating Humidity: 0 to 90% noncondensing NDAA Compliant: Yes Certifications: CE, FCC, IC
