UBIQUITI 802.3at / bt PoE Gigabit Unifi Switch with Layer 3 Features and SFP+, USW-Pro-24-POE Gen2
Product reference:
18-USW-Pro-24-PoE
UBIQUITI 802.3at/bt PoE Gigabit Unifi Switch with Layer 3 Features and SFP+, USW-Pro-24-POE Gen2
UBIQUITI 802.3at / bt PoE Gigabit Unifi Switch with Layer 3 Features and SFP+, USW-Pro-24-POE Gen2
Product reference:
18-USW-Pro-24-PoE
UBIQUITI 802.3at/bt PoE Gigabit Unifi Switch with Layer 3 Features and SFP+, USW-Pro-24-POE Gen2
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
12 month
Delivery from Lithuania in
2 - 4
business days
Build and expand your network with the UniFi® Switch, part of the Ubiquiti Networks® UniFi Enterprise System. The UniFi Switch PRO 24 PoE is a configurable Gigabit Layer-3 switch with auto-sensing 16 802.3at PoE+ and 8 802.3bt PoE++. It offers 24 RJ45 Ethernet ports and 2 SFP+ ports, providing 10 Gigabit PoE links to your devices and fiber uplink options to your enterprise network. The UniFi Switch PRO 24 PoE features an 1.3' touch LCM and integrated fans for quiet cooling. The LCM provides current switch states and the necessary information you need for quick diagnosis. Managed and configured by the UniFi Controller with UniFi Mobile app support, the UniFi Switch offers an extensive suite of advanced Layer-3 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port, Inter-VLAN routing, static routing and DHCP server. The UniFi Controller and mobile app allows admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
Note:Layer3 will be included in later software releases
| Dimensions | 442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72') |
| Weight With Rackmount Brackets | 4.30 kg (9.48 lb) 4.39 kg (9.68 lb) |
| Interfaces Networking Management | (24) 10/100/1000 RJ45 Ports (2) 1/10G SFP+ Ethernet Ports Ethernet In-Band |
| Power Method Universal Input USP RPS DC Input | 100-240VAC/50-60Hz 52VDC, 7.69A; 11.5VDC, 2.61A |
| Power Supply | AC/DC, Internal, 450W |
| Supported Voltage Range | 100 to 240VAC |
| Max. Power Consumption (Excluding PoE Output) | 50W |
| LEDs System RJ45 Data Ports SFP Data Ports | Status PoE; Speed/Link/Activity Link/Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 40°C (23 to 104°F) |
| Operating Humidity | 10 to 90% Non-condensing |
| Certifications | CE, FCC, IC |
| Sound Level* | |
|---|---|
| 25% PoE Load, 25° C Room Temperature | 0.9 dBr |
| 50% PoE Load, 25° C Room Temperature | 7.3 dBr |
| 100% PoE Load, 40°C | 18.8 dBr |
| PoE | |
| PoE Interfaces Ports 1-16 Ports 17-24 | POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-) 60W PoE++ IEEE 802.3bt, (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
| Max. PoE Wattage per Port by PSE 802.3at 802.3bt | 32W 64W |
| Voltage Range 802.3af Mode | 44-57V |
| Voltage Range 802.3at Mode | 50-57V |
*Background noise level: 27.5 dBa
