Access Point, TP-LINK, Omada, 300 Mbps, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 1xRJ45, Number of antennas 2, EAP110
Product reference:
2-6935364091620
Access Point, TP-LINK, Omada, 300 Mbps, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 1xRJ45, Number of antennas 2, EAP110
Product reference:
2-6935364091620
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
Not available
Flexible Placement
Easy mounting design & PoE
The EAP's elegant appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 supports Passive PoE to make deployment effortless and flexible.
Cloud Centralized Management - Anytime, Anywhere
Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Captive Portal
Guest Network with Facebook and SMS Support
The captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet.
- Cloud centralized management and Omada app for ultra convenience and easy management
- Supports passive PoE for convenient installation up to 100meters
- Ceiling mounting design with chassis make it easy to deploy on a wall or ceiling
- Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies
- Multi-SSID divides multiple wireless networks for different users
- Enterprise class Wi-Fi security help to decrease network security threats
- Supports management vlan for an enhanced network management
| 2.4 GHz | Yes |
| 5 GHz | No |
| 6 GHz | No |
| AC input voltage | 24 V |
| Access Control List (ACL) | Yes |
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 4 dBi |
| Antenna type | Internal |
| Antennas quantity | 2 |
| Cables included | AC |
| Cabling technology | 10/100Base-T(X) |
| Compliance certificates | CE/Federal Communications Commission (FCC)/RoHS |
| Depth | 170.5 mm |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10/100 Mbit/s |
| Frequency band | 2.4 - 2.4835 GHz |
| Harmonized System (HS) code | 85176990 |
| Height | 29.7 mm |
| LED indicators | Power |
| MAC address filtering | Yes |
| Maximum data transfer rate | 300 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Model name | 300Mbps Wireless N Ceiling Mount Access Point |
| Mounting kit | Yes |
| Networking standards | IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.1x |
| Number of SSID supported | 8 |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Package depth | 268 mm |
| Package height | 69 mm |
| Package type | Box |
| Package weight | 720 g |
| Package width | 246 mm |
| Placement | Ceiling,Wall |
| PoE adapter included | Yes |
| Power consumption (typical) | 2.8 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Product colour | White |
| Product Net Weight | 0.7 kg |
| Quality of Service (QoS) support | Yes |
| Quantity per pack | 1 pc(s) |
| Quick start guide | Yes |
| Rate limiting | Yes |
| Receiver sensitivity | 300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER |
| Reset button | Yes |
| Security algorithms | 128-bit WEP/152-bit WEP/64-bit WEP/HTTPS/SNMP/SNMPv2/SSH/WPA/WPA2-Enterprise/WPA2-PSK/WPA-PSK |
| Series | Omada |
| Service Set Identifier (SSID) features | Multiple SSIDs |
| Shipping Box Depth | 27 cm |
| Shipping Box Height | 7 cm |
| Shipping Box Weight | 0.81 kg |
| Shipping Box Width | 24.5 cm |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Summary | TP-Link Omada 300Mbps Wireless N Ceiling Mount Access Point. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise,.... Ethernet LAN data rates: 10,100 Mbit/s. Power over Ethernet (PoE). Product colour: White |
| Sustainability compliance | Yes |
| Syslog | Yes |
| Transmitting power (CE) | 19 dBm |
| Transmitting power (FCC) | 21 dBm |
| Unit Box Height | 0.07 |
| Unit Box Length | 0.27 |
| Unit Box Width | 0.245 |
| Unit Calculated Volume | 0.004631 cubm |
| Unit Calculated Weight | 0.81 kg |
| Unit Depth | 27 cm |
| Unit Height | 7 cm |
| Unit Width | 24.5 cm |
| Units per Shipping Box | 1 |
| Vendor Homepage | https://www.tp-link.com/en/business-networking/ceiling-mount-ap/eap110/v4/#overview |
| Virtual LAN features | VLAN mapping |
| VLAN support | Yes |
| Web-based management | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Width | 189.5 mm |
| Wireless isolation | Yes |
