Access Point, TP-LINK, 1200 Mbit / s, 1xLAN ports, 2xAntennas quantity, EAP225-OUTDOOR
Product reference:
2-6935364083571
Access Point, TP-LINK, 1200 Mbit / s, 1xLAN ports, 2xAntennas quantity, EAP225-OUTDOOR
Product reference:
2-6935364083571
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
Excellent Hardware Designs
With special design of its antenna, appearance, power options and installation methods, EAP225-Outdoor can perfectly fit for different scenarios both indoors and outdoors.
Detachable Antennas
EAP225-Outdoor is designed with 2 Omni-directional detachable antennas, which means other antennas can also be attached for your specific demands.
Wi-Fi That Goes the Distance
With high transmission power and high gain omnidirectional antennas, EAP225-Outdoor provides stable wireless coverage at a range up to 200m+* at 2.4GHz and 300m+* at 5GHz in outdoor settings.
Specially Designed Weatherproof Enclosure for
Outdoor Environment
Rated as IP65 during Ingress Protection testing, a resilient weatherproof enclosure protects the access points against harsh outdoor condition.
Efficient Centralized Network Management
With Omada Controller software, small and medium-sized businesses can take command of hundreds of indoor and outdoor access points all from a single location. It's network management as it should be - efficient and intuitive.
- Durable, weatherproof enclosure for outdoor Wi-Fi applications
- Up to 1200Mbps with 2×2 MIMO technology
- Omada Mesh Technology enables wireless connectivity between APs for extended range, making wireless deployments more flexible and convenient
- Supports Seamless Roaming so even video streams and voice calls are unaffected as users move between locations
- High transmission power and high gain antennas provide a long-range coverage area
- Cloud centralized management and Omada app for ultra convenience and easy management
- Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies
- 802.3af/Passive PoE (PoE Adapter Included) compatible and simple mounting design allow for flexible deployment and convenient installation
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| AC adapter included | Yes |
| Access Control List (ACL) | Yes |
| Airtime Fairness (ATF) | Yes |
| Antenna direction type | Omni-directional |
| Antenna features | Detachable antenna |
| Antenna gain level (max) | 4 dBi |
| Antenna type | External |
| Antennas quantity | 2 |
| Band steering | Yes |
| BeamForming | Yes |
| Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Compliance certificates | CE/Federal Communications Commission (FCC)/RoHS |
| Depth | 46 mm |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Harmonized System (HS) code | 85176990 |
| Height | 27 mm |
| International Protection (IP) code | IP65 |
| MAC address filtering | Yes |
| Maximum data transfer rate | 1200 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Model name | EAP225-OUTDOOR |
| Mounting kit | Yes |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3u |
| Number of SSID supported | 16 |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -30 - 70 °C |
| Output voltage | 24 V |
| Package depth | 270 mm |
| Package height | 100 mm |
| Package weight | 640 g |
| Package width | 140 mm |
| Placement | Pole,Wall |
| Power consumption (typical) | 10.5 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Product colour | White |
| Product Net Weight | 0.58 kg |
| Quality of Service (QoS) support | Yes |
| Quantity per pack | 1 pc(s) |
| Quick start guide | Yes |
| Rate limiting | Yes |
| Reset button | Yes |
| Security algorithms | 802.1x RADIUS |
| Service Set Identifier (SSID) features | Multiple SSIDs |
| Shipping Box Depth | 56 cm |
| Shipping Box Height | 30.5 cm |
| Shipping Box Weight | 13.6000003814697 kg |
| Shipping Box Width | 52 cm |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Summary | TP-Link Omada EAP225-Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1200 Mbit/s. Security algorithms: 802.1x RADIUS. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White |
| Sustainability compliance | Yes |
| Syslog | Yes |
| Transmitting power (CE) | 27 dBm |
| Transmitting power (FCC) | 22 dBm |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.27 |
| Unit Box Width | 0.14 |
| Unit Calculated Volume | 0.004441 cubm |
| Unit Calculated Weight | 0.68 kg |
| Unit Depth | 27 cm |
| Unit Height | 10 cm |
| Unit Width | 14 cm |
| Units per Shipping Box | 20 |
| Vendor Homepage | https://www.tp-link.com/uk/business-networking/outdoor-ap/eap225-outdoor/ |
| Virtual LAN features | VLAN mapping |
| VLAN support | Yes |
| Web-based management | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Width | 215 mm |
