Renogy 1000W 12V Voltage Converter

Renogy 1000W 12V Pure Sine Wave Power Inverter

Renogy 1000W Pure Sine Wave is a versatile 12V inverter for powering 230V devices in campers, boats and off-grid installations.
Offers 1000W continuous power and 2000W peak power, ensuring stable, high-quality AC voltage.
Technology pure sine wave protects sensitive electronics from voltage fluctuations and usually means quieter operation
of many devices (chargers, RTV, equipment with switching power supplies).

Key benefits

• Pure Sine Wave - safer power supply for sensitive devices and stable operation of electronics.


• High power and start-up reserve - 1000W continuous and 2000W peak for momentary load peaks.


• High efficiency - conversion efficiency > 90% reduces energy losses.


• Effective cooling - designed for stable operation over a wide temperature range.


• Comprehensive security - protection against too low/high voltage, overload, overheating and short circuit.


• Convenient installation - included in the set remote switch with 3 m cable and battery cables.

Main features

• Peak power 2000W and efficiency > 90%


• 230V output in the range of 220-240VAC


• LED indicators (including low/high voltage, overheating, overload, short circuit)


• Automatic recovery after low voltage protection trip


• Compatibility with various battery types (GEL, AGM, SLA, FLD, CAL, LI)

Technical specifications

• Parameters / Model: Renogy R-INVT-PUH1-101235 inverter


• Rated DC input voltage: 12VDC


• Input voltage range: 11-16 VDC


• Low voltage shutdown: 10VDC


• Low Voltage Protection - Automatic Recovery: Yes


• Constant output power: 1000 W


• Peak power: 2000 W


• Output voltage: 220-240 VAC


• Output frequency (rated): 50Hz ± 0.3


• Output waveform: pure sine wave


• Efficiency: > 90%


• Static current: 1.0 A


• Switching time: ≤ 50 ms


• Dimensions: 34.2 × 17.3 × 7.6 cm


• Libra: 2.6 kg
