MultiPlus-II 48/8000 110-100
Product reference: 39-8719076050568

The MultiPlus-II 48V 8000VA inverter with 110A charger is a powerful pure sine wave inverter for building large-scale energy storage systems. It supports LiFePO4 batteries, provides fast reserve switching, and provides high reliability in PV and off-grid systems.

MultiPlus-II 48 / 8000 110-100
MultiPlus-II 48 / 8000 110-100
MultiPlus-II 48 / 8000 110-100
MultiPlus-II 48 / 8000 110-100
MultiPlus-II 48 / 8000 110-100

MultiPlus-II 48/8000 110-100

Product reference: 39-8719076050568

The MultiPlus-II 48V 8000VA inverter with 110A charger is a powerful pure sine wave inverter for building large-scale energy storage systems. It supports LiFePO4 batteries, provides fast reserve switching, and provides high reliability in PV and off-grid systems.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
1 337,88 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
5 - 8
business days

Your message has been successfully sent!
Fill in the required fields*
MultiPlus-II 48/8000/110-100

is a modern energy converter that combines the function sine wave inverter and advanced battery charger The device is equipped with PowerControl technology and PowerAssist that support power management in overload situations. MultiPlus-II offers reliability, flexibility, and advanced features that are ideal for use in homes, vehicles, and energy storage systems.

Main functions of MultiPlus-II 48/8000/110-100


Advanced PowerControl and PowerAssist technology


MultiPlus-II uses innovative technologies PowerControl and PowerAssist, which prevent overloading of AC sources such as the mains or generator. The device adjusts battery charging and, if necessary, supplements power from stored energy in the batteries to ensure optimal system performance.

Ideal for Energy Storage Systems (ESS)


MultiPlus-II 48/8000/110-100 is a key element of modern Energy Storage Systems (ESS) By working with photovoltaic inverters and solar chargers, the device allows for maximum utilization of renewable energy sources. It can operate in on-grid, off-grid, and hybrid installations.

Remote monitoring and control


After connecting to the device GX such as Cerbo GX, the MultiPlus-II can be remotely monitored and controlled from anywhere in the world. Thanks to the free app VRM and the web portal, the user has full control over the system, which ensures security and reliability of operation in all conditions.

Versatility and flexibility of use


The MultiPlus-II is a device with a wide range of applications. Thanks to its advanced features, it can be installed in home power systems, as well as in vehicles and boats. It is compatible with many types of batteries, including high-performance ones. LiFePO4 batteries, which ensures long service life and flexibility in energy management.

Technical specifications MultiPlus-II 48/8000/110-100











  • Model: MultiPlus-II 48V 8000/110-100

  • PowerControl / PowerAssist: Yes

  • Transfer switch: 100 A

  • Maximum AC input current: 100 A


Inverter



  • Input voltage range (V DC): 38-66 V

  • Output voltage: 230 VAC ± 2%

  • Output frequency: 50Hz ± 0.1%

  • Output power at 25°C: 8000 VA

  • Output power at 25°C: 6400 W

  • Output power at 40°C: 5500 W

  • Output power at 65°C: 4000 W

  • Maximum apparent supply power: 8000 VA

  • Peak power: 15000 W

  • Maximum performance: 95%

  • Zero load power: 29 W

  • Zero load power in AES mode: 19 W

  • Zero load power in search mode: 3 W


Charger



  • AC input voltage range: 187-265 VAC

  • Input frequency: 45 - 65 Hz

  • Absorption charging voltage: 57.6V

  • Float charging voltage: 55.2V

  • Storage mode: 52.8V

  • Maximum battery charging current: 110 A

  • Battery temperature sensor: Yes


General



  • Auxiliary output: Yes (50A)

  • External AC sensor: Optional 50A or 100A

  • Programmable relay: Yes

  • Security: a - g

  • VE.Bus communication port: For parallel and three-phase operation, remote monitoring and system integration

  • General purpose communication port: Yes, 2x

  • Remote on/off: Yes


Characteristic features



  • Operating temperature range: -40 to +65°C (fan assisted cooling)

  • Humidity (non-condensing): maximum 95%


Other



  • Material and color: Steel, blue RAL 5012

  • Protection category: IP22

  • Battery connection: Four M8 screws (2 plus and 2 minus)

  • 230 V AC connection: M6 screws

  • Libra: 42 kg

  • Dimensions: 642 x 363 x 206 mm












MultiPlus-II 48/8000/110-100

is a high-performance, versatile device that is ideal for both home and mobile energy systems. Thanks to advanced energy management technologies, as well as PowerControl and PowerAssist, and compatibility with energy storage systems, it is a perfect solution for people who are looking for a modern, reliable and flexible power system.
