EPEVER IPB500-12(E / R) 12V 500W voltage converter
Product reference: 39-5906765148450

The EPEVER IPB500 is a compact 500W inverter that provides stable, pure sine wave power, ideal for sensitive electronic devices. With automatic grid-connection, advanced safety features, and remote monitoring capabilities (RS485), the IPB500 is ideal for off-grid systems—at home, in a camper, or on a camping trip.

Przetwornica napięcia EPEVER IPB500-12(E / R) 12V 500W
Przetwornica napięcia EPEVER IPB500-12(E / R) 12V 500W
Przetwornica napięcia EPEVER IPB500-12(E / R) 12V 500W

EPEVER IPB500-12(E / R) 12V 500W voltage converter

Product reference: 39-5906765148450

The EPEVER IPB500 is a compact 500W inverter that provides stable, pure sine wave power, ideal for sensitive electronic devices. With automatic grid-connection, advanced safety features, and remote monitoring capabilities (RS485), the IPB500 is ideal for off-grid systems—at home, in a camper, or on a camping trip.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
224,11 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
5 - 8
business days

Your message has been successfully sent!
Fill in the required fields*

EPEVER IPB500-12(E/R) converter



High energy efficiency


Thanks to the advanced control algorithm and high power factor (up to 1), the device guarantees maximum energy efficiency.

Compatible


The use of advanced energy conversion technologies ensures stable and clean AC voltage, compatible with most electrical devices.

Remote control


The RS485 port enables remote monitoring and management of the inverter, which is particularly useful in complex off-grid installations.

Main features:



  • Pure sine wave output

  • Electrical isolation between input and output

  • Automatic mains bypass function (mains power supply when available)

  • RS485 communication port enabling remote monitoring

  • External switch to extend inverter control functions and reduce energy consumption

  • Output power factor up to 1

  • Input protection: against too low and too high voltage

  • Output protection: overload, short circuit and overheating

  • Equipped with a type E socket (popular in Poland and other European countries)


Compact, perfect for a camper


Thanks to its small size and lightweight design, it easily fits into the limited space of a camper. It's the perfect solution for mobile off-grid installations where every centimeter counts.

Integration with EPEVER systems


Thanks to the external switch and full compatibility with other EPEVER products, the user can expand functionality and optimize energy consumption.

Key features of the system:



  • High reliability: Solid construction and careful manufacturing ensure long and stable operation.

  • Advanced technology: Extensive protection functions protect the device and connected receivers.

  • Mains bypass switch function: Guarantees continuous power supply without the need for manual intervention.

  • High input voltage: Perfect integration with photovoltaic systems.

  • Pure sine wave output: Minimizes interference and is safe for electronics.

  • Environmentally friendly: Supports energy efficiency and reduces CO emissions.



Technical specifications


Model: IPB500-12

  • AC input voltage range: 190~265 VAC

  • Quick acting fuse - Rated current: 3A

  • AC input frequency range: 45Hz~55Hz / 55Hz~65Hz

  • Nominal battery voltage: 12VDC

  • Battery operating voltage range: 10.8 ~ 16.0VDC

  • Rated battery input current: 46.7A

  • Continuous output power: 500W (at 35°C and rated battery voltage)

  • Instantaneous (overload) power: 1000W (for 5 seconds)

  • Inverter output voltage: 220VAC (±3%), 230VAC (-6%~+3%), 240VAC (-9%~+3%)

  • Inverter output frequency: 50/60Hz ± 0.2%

  • Output voltage waveform: Pure sine wave

  • Harmonic distortion: ≤ 3% (resistive load)

  • Load power factor: 0.2 ~ 1 (with load power ≤ continuous output power)

  • Maximum output current: 4.6A

  • Rated output current: 2.3A

  • Rated efficiency: 90.20%

  • Maximum efficiency: > 91.0% (at 40% load)

  • No-load current: < 0.15A

  • No-load current: < 0.9A

  • Communication port: RS485 (5VDC/200mA)

  • Input terminal: M6

  • Dimensions (L × W × H): 335 × 160 × 73 mm

  • Installation dimensions (L × W): 311 × 75 mm

  • Mounting hole sizes: Φ5 mm

  • Net weight: 2.3 kg

  • Operating temperature: -20 ~ +60 (according to power derating curve)

  • Storage temperature: -35 ~ +70

  • Relative humidity: ≤ 95% (non-condensing)

  • Housing protection class: IP20

  • Working height: < 5000 m (Above 1000 m, power derating according to IEC62040 applies)
