EPEVER IPB1500-12(E / R) 12V 1500W voltage converter
Product reference:
39-5906765148474
The EPEVER IPB1500 is a compact 1500W inverter that provides stable, pure sine wave power, ideal for sensitive electronic devices. With automatic switching to mains power, advanced safety features, and remote monitoring capabilities (RS485), the IPB1500 is ideal for off-grid systems—at home, in a camper, or while camping.
EPEVER IPB1500-12(E / R) 12V 1500W voltage converter
Product reference:
39-5906765148474
The EPEVER IPB1500 is a compact 1500W inverter that provides stable, pure sine wave power, ideal for sensitive electronic devices. With automatic switching to mains power, advanced safety features, and remote monitoring capabilities (RS485), the IPB1500 is ideal for off-grid systems—at home, in a camper, or while camping.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
5 - 8
business days
EPEVER IPB1500-12(E/R) converter
High energy efficiency
Thanks to the advanced control algorithm and high power factor (up to 1), the device guarantees maximum energy efficiency.
Compatible
The use of advanced energy conversion technologies ensures stable and clean AC voltage, compatible with most electrical devices.
Remote control
The RS485 port enables remote monitoring and management of the inverter, which is particularly useful in complex off-grid installations.
Main features:
- Pure sine wave output
- Electrical isolation between input and output
- Automatic switch to mains bypass
- RS485 communication port for remote monitoring
- External control and energy saving switch
- Output power factor up to 1
- Protections: too low/high input voltage, overload, short circuit, overheating
- Type E socket - compatible with Polish standards
Compact, perfect for a camper
Small size and lightweight design enable installation in confined spaces. Perfect for mobile off-grid installations.
Integration with EPEVER systems
Full compatibility and the ability to expand functionality thanks to an external switch and integration with other EPEVER products.
Key features of the system:
- High reliability - proven quality and solid construction
- Advanced technology - device protection and safe operation
- Network bypass - smooth switching to mains power supply
- High input voltage - compatibility with PV installations
- Pure sine wave signal - safe for devices, no interference
- Environmentally friendly - reduction of carbon footprint, efficient use of energy
Technical specifications
Parameters / Model: IPB1500-12
- AC input voltage range: 190~265 VAC
- Quick acting fuse - Rated current: 8A
- AC input frequency range: 45Hz~55Hz / 55Hz~65Hz
- Nominal battery voltage: 12VDC
- Battery operating voltage range: 10.8 ~ 16.0VDC
- Rated battery input current: 141.1A
- Continuous output power: 1500 W (at 35°C and rated battery voltage)
- Instantaneous output power (5 sec): 3000W
- Inverter output voltage: 220VAC (±3%), 230VAC (-6%~+3%), 240VAC (-9%~+3%)
- Inverter output frequency: 50/60Hz ± 0.2%
- Output voltage waveform: Pure sine wave
- Harmonic distortion of the output voltage: ≤ 3% (resistive load)
- Load power factor: 0.2 ~ 1 (load power ≤ continuous output power)
- Maximum output current: 13.8A
- Rated output current: 6.9A
- Rated output efficiency: 89.70%
- Maximum output efficiency: > 93.0% (30% load)
- No-load current: < 0.2A
- No-load current: < 1.2A
- Communication port: RS485 (5VDC / 200mA)
- Input terminal: M6
- Dimensions (L × W × H): 387 × 228 × 118 mm
- Mounting dimensions: 361 × 145 mm
- Mounting hole sizes: Φ6 mm
- Net weight: 6.0 kg
- Operating temperature range: -20 ~ +60 (according to power derating curve)
- Storage temperature range: -35 ~ +70
- Relative humidity: ≤ 95% (NC)
- Case: IP20
- Working height: < 5000 m (above 1000 m - power reduction according to IEC62040)
