EPEVER IPB1000-12(E / R) 12V 1000W voltage converter
Product reference: 39-5906765148467

The EPEVER IPB1000 is a compact 1000W inverter that provides stable, pure sine wave power, ideal for sensitive electronic devices. With automatic grid-connection, advanced safety features, and remote monitoring capabilities (RS485), the IPB1000 is ideal for off-grid systems—at home, in a camper, or on a camping trip.

Przetwornica napięcia EPEVER IPB1000-12(E / R) 12V 1000W
Przetwornica napięcia EPEVER IPB1000-12(E / R) 12V 1000W
Przetwornica napięcia EPEVER IPB1000-12(E / R) 12V 1000W

EPEVER IPB1000-12(E / R) 12V 1000W voltage converter

Product reference: 39-5906765148467

The EPEVER IPB1000 is a compact 1000W inverter that provides stable, pure sine wave power, ideal for sensitive electronic devices. With automatic grid-connection, advanced safety features, and remote monitoring capabilities (RS485), the IPB1000 is ideal for off-grid systems—at home, in a camper, or on a camping trip.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
299,92 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
5 - 8
business days

Your message has been successfully sent!
Fill in the required fields*

EPEVER IPB1000-12(E/R) converter



High energy efficiency


Thanks to the advanced control algorithm and high power factor (up to 1), the device guarantees maximum energy efficiency.

Compatible


The use of advanced energy conversion technologies ensures stable and clean AC voltage, compatible with most electrical devices.

Remote control


The RS485 port enables remote monitoring and management of the inverter, which is particularly useful in complex off-grid installations.

Main features:



  • Pure sine wave output

  • Electrical isolation between input and output

  • Automatic switch to mains bypass

  • RS485 port for remote monitoring

  • External switch to reduce energy consumption

  • Output power factor up to 1

  • Protection: overload, short circuit, thermal, voltage

  • Type E socket - compatible with European installations


Compact, perfect for a camper


Thanks to its small size and lightweight design, it easily fits into the limited space of a camper. It's the perfect solution for mobile off-grid installations.

Integration with EPEVER systems


Compatibility with an external switch and other EPEVER products allows for extended functionality and optimized energy consumption.

Key features of the system:



  • High reliability: thanks to its solid construction and precise workmanship

  • Advanced technology: full protection of the device and connected receivers

  • Network Bypass: automatic switching to mains power

  • High input voltage: ideal for photovoltaic applications

  • Clean output signal: no interference, safe operation of devices

  • Ecological solution: support for renewable energy and reduction of CO emissions



Technical specifications


Parameters / Model: IPB1000-12

  • AC input voltage range: 190~265 VAC

  • Quick-acting fuse - rated current: 5A

  • AC input frequency range: 45Hz~55Hz / 55Hz~65Hz

  • Nominal battery voltage: 12VDC

  • Battery operating voltage range: 10.8 ~ 16.0VDC

  • Rated battery input current: 92.3A

  • Continuous output power: 1000 W at 35°C and rated battery voltage

  • Instantaneous (overload) power for 5 seconds: 2000W

  • Inverter output voltage: 220VAC (±3%), 230VAC (-6%~+3%), 240VAC (-9%~+3%)

  • Inverter output frequency: 50/60Hz ± 0.2%

  • Output voltage waveform: Pure sine wave

  • Total harmonic distortion: ≤ 3% (resistive load)

  • Load power factor: 0.2 ~ 1 (load power ≤ continuous output power)

  • Maximum output current: 9.2A

  • Rated output current: 4.6A

  • Rated efficiency: 91.40%

  • Maximum efficiency: > 93.0% (at 40% load)

  • No-load current: < 0.2A

  • No-load current: < 1.1A

  • Communication port: RS485 (5VDC/200mA)

  • Input terminal: M6

  • Dimensions (L x W x H): 371 × 228 × 118 mm

  • Mounting dimensions (length x width): 345 × 145 mm

  • Mounting hole sizes: Φ6 mm

  • Net weight: 4.8 kg

  • Operating temperature range: -20 ~ +60 (according to power derating curve)

  • Storage temperature range: -35 ~ +70

  • Relative humidity: ≤ 95% (NC)

  • Case: IP20

  • Working height: < 5000 m (when exceeding 1000 m - power reduction according to IEC62040)
