ICY BOX IB-AD1030-C

ICY BOX Adapter USB Type-C to 3x HDMI. Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C, Hub interfaces: HDMI. Data transfer rate: 10000 Mbit/s, Maximum refresh rate: 144 Hz, Supported graphics resolutions: 3840 x 2160, 7680 x 4320. Power supply type: USB. Width: 45 mm, Depth: 310 mm, Height: 14 mm. Quantity per pack: 1 pc(s), Package width: 25 mm, Package depth: 170 mm

More screens. More clarity. Triple HDMI®.
Expand your screen space with support for up to three HDMI® displays. Ideal for multitasking, you can connect multiple monitors to create a wider digital workspace using just one adapter, no complicated setup or extra hardware required.

Brilliant 8K resolution on one monitor
Enjoy sharp, detailed visuals with support for resolutions up to 8K on Windows®. A single connected monitor can reach up to 8K@60 Hz, delivering crisp image quality for high-resolution content. Ideal for modern displays, this adapter supports clear output across a wide range of use cases.

One port does it all
Designed for devices with a USB Type-C® port, this adapter makes display expansion quick and easy. A single connection gives access to multiple video outputs, offering a simple and clean solution for adding external monitors to supported notebooks or tablets.

Ports & interfaces

Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Hub interfaces: HDMI
HDMI ports quantity: 3
Ports quantity: 3
Feature: USB Type-C DisplayPort Alternate Mode

Features

Data transfer rate: 10000 Mbit/s
Maximum refresh rate: 144 Hz
Supported graphics resolutions: 3840 x 2160, 7680 x 4320
Maximum resolution (HDMI): 7680 x 4320 pixels
Product colour: Black
Housing material: Aluminium
Feature: HDCP
Cable type: Round cable
Cable length: 0.2 m
Feature: Plug and Play
Country of origin: China

Network

Feature: UASP support

Power

Power supply type: USB

System requirements

Windows operating systems supported: Yes
Mac operating systems supported: Yes

Weight & dimensions

Width: 45 mm
Depth: 310 mm
Height: 14 mm
Weight: 92 g

Packaging data

Quantity per pack: 1 pc(s)
Package width: 25 mm
Package depth: 170 mm
Package height: 90 mm
Package volume: 55000 cm³
Package weight: 100 g

Packaging content

Feature: Manual

Certificates

Feature: Waste Electrical and Electronic Equipment (WEEE) compliance

Logistics data

Harmonized System (HS) code: 84718000

Technical details

Compliance certificates: CE, Federal Communications Commission (FCC)

Other features

Chipset: RTD2146 + VL103
