Digitus DS-55518 AV extender

Digitus HDMI IP Extender Receiver, Full HD. Type: AV receiver, Maximum resolution: 1920 x 1080 pixels, Cable types supported: Cat6, Cat6a, Cat7, Cat8. Connectivity technology: Wired. Operating voltage: 5 V, Input current: 2 A, Power consumption (typical): 8 W. Width: 59 mm, Depth: 100 mm, Height: 25 mm. Package width: 145 mm, Package depth: 190 mm, Package height: 60 mm

Use additional receiver units and your existing network infrastructure/network switches to display video content on up to 253 screens (IP connection)

- Extends Full HD AV signals over CAT-6 cable to unlimited distances via the existing network infrastructure or using commercially available network switches
- Supports resolutions of up to 1080p/60Hz, Full HD
- Supports CAT 6, 6A, 7, 8 network cables
- IR interface enables remote control of the input source from the output screen
- HDCP 1.3
- Video bandwidth: 1.65 Gbps

Expand the HDMI IP Extender Set (DS-55517) with additional receiver units to display your AV content on multiple monitors at the same time. The set extends Full HD AV signals up to 120 m via a CAT6 network cable (point-to-point connection). In addition, you can use network switches and the individual receiver units (DS-55518) to distribute your video content to up to 253 displays via the existing network (IP connection) and extend it to an unlimited distance.

Features

Type: AV receiver
Maximum resolution: 1920 x 1080 pixels
Cable types supported: Cat6, Cat6a, Cat7, Cat8
Maximum transfer distance: 120 m
Maximum refresh rate: 60 Hz
LED indicators: Yes
Supported video modes: 1080p
Bandwidth: 1.65 Gbit/s
Cable length: 1.5 m
Feature: HDCP
Material: Metal
Feature: Wall mountable
HDCP version: 1.3
Product colour: Black

Ports & interfaces

Connectivity technology: Wired
RJ-45 input ports: 1
Number of HDMI outputs: 1
Remote (IR) input: 1
Feature: DC-in jack

Power

Operating voltage: 5 V
Input current: 2 A
Power consumption (typical): 8 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C

Weight & dimensions

Width: 59 mm
Depth: 100 mm
Height: 25 mm
Weight: 165 g

Packaging data

Package width: 145 mm
Package depth: 190 mm
Package height: 60 mm
Package weight: 425 g

Packaging content

Feature: AC adapter included
Cables included: IR
Feature: Manual
Feature: Mounting kit

Technical details

Country of origin: China
Package volume: 1653 cm³

Logistics data

UK Trade Tariff code: 85176200
