Digitus DS-55329 AV extender

Digitus Wireless HDMI Receiver for DS-55328. Type: AV receiver, Maximum resolution: 3840 x 2160 pixels, Maximum refresh rate: 30 Hz. Connectivity technology: Wired & Wireless, USB connector type: USB Type-A, USB Type-C. Power consumption (typical): 5 W. Width: 154 mm, Depth: 77.5 mm, Height: 21 mm. Quantity per pack: 1 pc(s), Package width: 235 mm, Package depth: 110 mm

Expand the 4K Wireless HDMI KVM Extender Set (DS-55328) to up to 4 receivers (output devices)

- Point-to-multipoint connection - 1x transmitter (source) + up to 4x receivers (output device)
- Supports wireless AV signal transmission with resolutions up to 4K UHD (2160p/30Hz max) via transmitter
- Touch Screen Back Control - Supports touch panels (via USB connection on the receiver)
- Radio channel: IEEE 802.11.b/g/n/ac
- Frequency band: Dual band, 2.4/5G
- Compression: H.265
- Latency: approx. 100 ms
- AES 128 bit encryption
- Authentication protocol: WPA2 (WPAS-PSK / WPA2-Enterprise)
- HDMI version: 2.0

With this additional receiver unit, you can expand the 4K Wireless HDMI KVM Extender Set (DS-55328) to up to 4 receivers (output devices). Distribute your AV signals wirelessly to up to 4 screens.

Features

Type: AV receiver
Maximum resolution: 3840 x 2160 pixels
Maximum refresh rate: 30 Hz
LED indicators: Status
Supported video modes: 1080p, 2160p
Supported graphics resolutions: 3840 x 2160, 1920 x 1080 (HD 1080)
Security algorithms: WPA2, 128-bit AES
Video compression formats: H.265
Feature: On/off switch
Material: Metal
Feature: Plug and Play
Product colour: Black

Ports & interfaces

Connectivity technology: Wired & Wireless
Feature: Wi-Fi
Number of HDMI outputs: 1
HDMI version: 2.0
USB ports quantity: 3
USB connector type: USB Type-A, USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

Power

Power consumption (typical): 5 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Weight & dimensions

Width: 154 mm
Depth: 77.5 mm
Height: 21 mm
Weight: 330 g

Packaging data

Quantity per pack: 1 pc(s)
Package width: 235 mm
Package depth: 110 mm
Package height: 70 mm
Package weight: 580 g

Packaging content

Feature: AC adapter included
Cables included: HDMI, USB
Feature: Quick start guide
