Digitus DS-55323 AV extender

Digitus 4K Wireless HDMI Extender Set, 30 m, 4K/30Hz. Type: AV transmitter & receiver, Maximum resolution: 3840 x 2160 pixels, Maximum transfer distance: 30 m. Connectivity technology: Wired & Wireless. Power source type: USB, Operating voltage: 5 V, Power consumption (transmitter) (max): 3 W. Receiver dimensions (WxDxH): 34 x 81 x 13 mm, Receiver weight: 28 g, Transmitter dimensions (WxDxH): 34 x 81 x 13 mm. Quantity per pack: 2 pc(s), Package width: 119 mm, Package depth: 119 mm

Transmits HDMI video and audio signals wirelessly in UHD 4K/30Hz over a distance of up to 30 m with unrestricted visibility

- Wireless HDMI signal transmission up to 30 m (unrestricted view)
- Point-to-point connection - 1x transmitter (source) + 1x receiver (output device)
- Supports resolutions up to 4K UHD (4K/30Hz)
- Simple operation and handling thanks to Plug & Play - plug in and go, no drivers or software required
- Automatic pairing & connection: Automatically establishes a connection via the most advantageous WiFi channel to ensure the best possible WiFi performance
- Power supply via USB-C connection
- AES 128 bit encryption
- WPA2 protocol
- HDMI 2.0/1.4
- HDCP 2.2/1.4

Experience cable-free audio and video transmission in razor-sharp UHD 4K/30Hz with the 4K Wireless HDMI Extender. The set enables easy setup without drivers or software thanks to Plug & Play. With a range of up to 30 meters in clear view, it guarantees reliable transmission. AES 128-bit encryption and the WPA2 protocol ensure secure data transmission. Compatible with HDMI 2.0/1.4 and HDCP 2.2/1.4. Ideal e.g. for home cinemas, conference rooms and training facilities. Discover the freedom of wireless entertainment!

Features

Type: AV transmitter & receiver
Maximum resolution: 3840 x 2160 pixels
Maximum transfer distance: 30 m
Maximum refresh rate: 30 Hz
Audio output channels: 2.0 channels
LED indicators: Status
Supported video modes: 1080p, 2160p
Supported graphics resolutions: 1920 x 1080 (HD 1080), 3840 x 2160
Audio formats supported: PCM
Security algorithms: 128-bit AES, WPA2
Video compression formats: H.265
Feature: HDCP
Material: ABS
Feature: Plug and Play
HDCP version: 2.2
Product colour: Black, Silver

Ports & interfaces

Connectivity technology: Wired & Wireless
Feature: Wi-Fi
HDMI in: 1
Number of HDMI outputs: 1
HDMI version: 2.0

Power

Power source type: USB
Operating voltage: 5 V
Power consumption (transmitter) (max): 3 W
Power consumption (receiver) (max): 4 W
Power consumption (transmitter) (max): 1000 mA
Power consumption (receiver) (max): 600 mA

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Weight & dimensions

Receiver dimensions (WxDxH): 34 x 81 x 13 mm
Receiver weight: 28 g
Transmitter dimensions (WxDxH): 34 x 81 x 13 mm
Transmitter weight: 31 g

Packaging data

Quantity per pack: 2 pc(s)
Package width: 119 mm
Package depth: 119 mm
Package height: 49 mm
Package weight: 290 g

Packaging content

Cables included: USB Type-A, USB Type-C
Feature: Quick start guide
