Digitus DS-55321 KVM extender

Digitus Wireless HDMI KVM Extender Set, 200 m. Type: Transmitter & receiver, Connectivity technology: Wireless, Maximum transfer distance: 200 m. Transmitter video port type: HDMI, Transmitter local video port type: HDMI, Transmitter local keyboard/mouse port type: USB. Receiver local video port type: HDMI, Receiver local keyboard/mouse port type: USB. USB port type: USB Type A/USB Type-C. Power consumption (transmitter) (max): 2.5 W, Power consumption (receiver) (max): 2.5 W

Transmits HDMI video and audio signals wirelessly in Full HD over a distance of up to 200 m in clear view and offers KVM functionality

- Wireless HDMI signal transmission up to 200 m (with a clear view)
- Point-to-point connection - 1x transmitter (source) + 1x receiver (output device)
- Supports transmission resolutions up to Full HD (1080p / 60Hz)
- KVM functionality for connecting mouse & keyboard
- Touch Screen Back Control - Supports touch screen panels (via USB connection on the receiver)
- Supports input signals with up to 4K/60Hz
- HDMI loop-out for connecting a local monitor to the transmitter unit
- Auto-pairing function - no configuration necessary
- AES 128 bit encryption
- WPA2 protocol

The Wireless HDMI® KVM Extender Set transmits your HDMI® video and audio signals in Full HD resolution wirelessly over a distance of up to 200 m (unrestricted view). Thanks to KVM functionality, a mouse/keyboard can be connected to the receiver unit, allowing the signal source to be controlled directly at the output device. A local monitor can be connected via the HDMI loop-out on the transmitter unit to control the output on the receiver. The auto-pairing function promises simple installation.

Features

Type: Transmitter & receiver
Connectivity technology: Wireless
Maximum transfer distance: 200 m
Maximum digital resolution: 1920 x 1080 pixels
Product colour: Black
Feature: Easy to install
Feature: Plug and Play

Transmitter

Transmitter video port type: HDMI
Transmitter local video port type: HDMI
Transmitter local keyboard/mouse port type: USB

Receiver

Receiver local video port type: HDMI
Receiver local keyboard/mouse port type: USB

Ports & interfaces

USB port type: USB Type A/USB Type-C

Power

Power consumption (transmitter) (max): 2.5 W
Power consumption (receiver) (max): 2.5 W

Weight & dimensions

Transmitter width: 15.5 cm
Transmitter depth: 7.9 cm
Transmitter height: 2.2 cm
Transmitter weight: 326 g
Receiver width: 15.5 cm
Receiver depth: 7.9 cm
Receiver height: 2.2 cm
Receiver weight: 326 g

Packaging data

Package width: 230 mm
Package depth: 250 mm
Package height: 66 mm
Package weight: 1.16 kg

Packaging content

Feature: AC adapter included
Cables included: USB Type-A to Micro-USB Type-B
Feature: Manual

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Other features

Wi-Fi standards: Wi-Fi 5 (802.11ac)

Technical details

Maximum resolution: 1920 x 1080 pixels
Package volume: 3795 cm³

Logistics data

Country of origin: China
UK Trade Tariff code: 85176200
Harmonized System (HS) code: 84733080
