Digitus DS-55122 AV extender

Digitus 4K HDMI extender via CAT / IP (set). Type: AV transmitter & receiver, Maximum resolution: 3840 x 2160 pixels, Cable types supported: Cat5, Cat5e, Cat6. Connectivity technology: Wired. Operating voltage (transmitter): 5 V, Output current: 2 A, Operating voltage (receiver): 5 V. Width: 107.3 mm, Depth: 94 mm, Height: 23.7 mm. Package width: 199 mm, Package depth: 149 mm, Package height: 80 mm

Use additional receiver units (DS-55123) and your existing network infrastructure to display video content on up to 253 screens (IP connection)

- Use additional receiver units (DS-55123) and your existing network infrastructure to display your video content on up to 253 screens (IP connection)
- Extends 4K video content up to 120 m with a CAT 6 cable (point-to-point connection)
- Extension of the signal (unlimited distance) via the existing local network infrastructure (IP connection)
- Supports 4K (30Hz), 3840x2160p resolution
- Supports CAT 5, CAT 5e, CAT 6 and CAT 7 network cables
- HDMI bandwidth: 10.2 Gbit / s (max.)
- Supports HDCP 1.4

The 4K HDMI Extender Set (DS-55122) is a high-performance video distribution system consisting of a transmitter/receiver unit. It extends 4K HDMI signals up to 120 m via a CAT6 network cable (point-to-point connection). In addition, you can use a network switch and the individual receiver units (DS-55123) to distribute your video content to up to 253 displays via the existing network (IP connection). The additional integrated unidirectional IR interface enables remote control of the input source.

Features

Type: AV transmitter & receiver
Maximum resolution: 3840 x 2160 pixels
Cable types supported: Cat5, Cat5e, Cat6
Maximum transfer distance: 120 m
Supported video modes: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Bandwidth: 10.2 Gbit/s
Feature: HDCP
Material: Metal
Colour depth: 24 bit
Feature: 3D
Product colour: Black

Ports & interfaces

Connectivity technology: Wired
RJ-45 input ports: 1
RJ-45 output ports: 1
HDMI in: 1
Number of HDMI outputs: 1
HDMI version: 1.4
Remote (IR) input: 1
Remote (IR) output: 1
Feature: DC-in jack

Power

Operating voltage (transmitter): 5 V
Output current: 2 A
Operating voltage (receiver): 5 V
Power consumption (typical): 4 W

Operational conditions

Operating temperature (T-T): 0 - 60 °C

Weight & dimensions

Width: 107.3 mm
Depth: 94 mm
Height: 23.7 mm
Weight: 167 g

Packaging data

Package width: 199 mm
Package depth: 149 mm
Package height: 80 mm
Package weight: 845 g

Packaging content

Feature: AC adapter included
Feature: Manual
Feature: IR blaster included
Feature: IR receiver included

Technical details

Country of origin: China
Package volume: 2372.08 cm³

Logistics data

UK Trade Tariff code: 85176200
