Digitus DS-55100-1 AV extender

Digitus HDMI extender set, Full HD, 50 m. Type: AV transmitter & receiver, Maximum resolution: 1920 x 1080 pixels, Cable types supported: Cat6, Cat6a, Cat7. Connectivity technology: Wired. Receiver dimensions (WxDxH): 67 x 72 x 23 mm, Transmitter dimensions (WxDxH): 67 x 72 x 23 mm. Package width: 150 mm, Package depth: 200 mm, Package height: 80 mm. Master (outer) case width: 315 mm, Master (outer) case length: 425 mm, Master (outer) case height: 420 mm

Extends the maximum length for HDMI cables to up to 50 m using only a single network cable between a transmitter and a receiver unit

- Extends the maximum length for HDMI cables to up to 50 m via a simple network cable
- Highest supported video resolution: 1080p / 60 Hz
- Supports CAT 6, CAT 6A and CAT 7 network cables
- Manual EDID switch - Allows you to set the resolution and audio format on the transmitter unit
- HDMI Loop Out - Enables the connection of a local monitor to the transmitter unit
- Supports PoE (Power over Ethernet) - therefore a power supply for the receiver unit is not required

The Digitus HDMI Extender Set, Full HD offers an extender solution up to 50 m for the highest demands. It transmits digital video and audio signals over a maximum length of up to 50 m. The highest supported video resolution is 1080p / 60Hz. There is an EDID switch on the transmitter unit with which the resolution and audio format of the output signal can be regulated. There is also an HDMI Loop Out port on the transmitter, which enables the connection of a local monitor. Thanks to PoC (Power over cable) support, only the transmitter unit needs to be supplied with power. Two bidirectional infrared units (transmitter, receiver) are supplied, which can be used for remote control of the connected input source.

Features

Type: AV transmitter & receiver
Maximum resolution: 1920 x 1080 pixels
Cable types supported: Cat6, Cat6a, Cat7
Maximum transfer distance: 50 m
Maximum refresh rate: 60 Hz
Supported video modes: 1080p
Bandwidth: 4.95 Gbit/s
Feature: HDCP
Material: Metal
Colour depth: 8 bit
Feature: HDCP & EDID bypass
Product colour: Black

Ports & interfaces

Connectivity technology: Wired
RJ-45 input ports: 1
RJ-45 output ports: 1
HDMI in: 1
Number of HDMI outputs: 2
Remote (IR) input: 1
Remote (IR) output: 1
Feature: DC-in jack

Power

Feature: Power over Ethernet (PoE)

Weight & dimensions

Receiver dimensions (WxDxH): 67 x 72 x 23 mm
Transmitter dimensions (WxDxH): 67 x 72 x 23 mm

Packaging data

Package width: 150 mm
Package depth: 200 mm
Package height: 80 mm
Package weight: 1.15 kg

Packaging content

Feature: Manual
Feature: IR blaster included
Feature: IR receiver included

Technical details

Country of origin: China
Package volume: 2400 cm³

Logistics data

UK Trade Tariff code: 85176200
Master (outer) case width: 315 mm
Master (outer) case length: 425 mm
Master (outer) case height: 420 mm
Master (outer) case gross weight: 11.5 kg
Master (outer) case volume: 56227 cm³
