LogiLink UA0396 interface hub

LogiLink USB 3.2 Gen1, 4-port hub, black. Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-A, Hub interfaces: USB 3.2 Gen 1 (3.1 Gen 1) Type-A. Data transfer rate: 5000 Mbit/s, Product colour: Black, Housing material: Acrylonitrile butadiene styrene (ABS). Power supply type: USB, Power supply: 4.5 W, Input voltage: 5 V. Windows operating systems supported: Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1, Mac operating systems supported: MacOS, Other operating systems supported: Android, ChromeOS. Width: 257 mm, Depth: 42 mm, Height: 12 mm

The hub supports the modern USB 3.2 Gen1 standard and allows you to connect up to 4 USB devices (4x USB 3.2 Gen1 ports). Of course, you can also connect and use devices of older USB generations. Easy connection via plug & play. USB 3.2 transfer rates of up to 5 Gbit/s.

Ports & interfaces

Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Hub interfaces: USB 3.2 Gen 1 (3.1 Gen 1) Type-A
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ports quantity: 4

Features

Data transfer rate: 5000 Mbit/s
Product colour: Black
Housing material: Acrylonitrile butadiene styrene (ABS)
Feature: Overcurrent protection
LED indicators: Yes
Cable type: Round cable
Cable length: 0.15 m
Country of origin: China

Power

Power supply type: USB
Power supply: 4.5 W
Input voltage: 5 V
Input current: 0.9 A

System requirements

Windows operating systems supported: Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Mac operating systems supported: MacOS
Linux operating systems supported: Yes
Other operating systems supported: Android, ChromeOS

Weight & dimensions

Width: 257 mm
Depth: 42 mm
Height: 12 mm
Weight: 36 g

Packaging data

Quantity per pack: 1 pc(s)
Package width: 120 mm
Package depth: 75 mm
Package height: 25 mm
Package weight: 40 g
Package type: Hanging box

Packaging content

Feature: Manual

Operational conditions

Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 25 - 60%

Sustainability

Feature: Sustainability compliance

Logistics data

Master (outer) case width: 400 mm
Master (outer) case length: 270 mm
Master (outer) case height: 245 mm
Master (outer) case gross weight: 4.15 kg
Products per master (outer) case: 100 pc(s)

Technical details

Compliance certificates: CE, UKCA
