Lindy 73428 mobile device charger

Lindy 73428. Charger type: Indoor, Power source type: AC, Charger compatibility: Universal. Input voltage: 100 - 240 V, Maximum output voltage: 20 V. USB 2.0 ports quantity: 1, USB Type-C ports quantity: 1, Fast charging, Power protection features: Over current, Over voltage, Overheating, Short circuit. Product colour: White

The Lindy 65W USB Type A & C GaN Charger can charge two devices simultaneously. 65W Power Delivery and PPS are supported by the USB Type C port while the USB Type A port provides fast charging with up to 45W. When both ports are used in parallel a maximum power of 20W will be provided.

Featuring both a USB Type C female and a USB Type A female port this charger is ideal for use with most popular smartphones and iOS devices. Supporting power delivery of 65W and PPS (Progammable Power Supply), connected devices can be provided with faster and smarter charging than what is possible from a standard Type C charger supplied with many devices; it can modify voltage and current in real-time by feeding maximum power based on a device's charging status.

For safe charging the device includes overcharge, overcurrent, overtemperature and short circuit protection. As this charger is rated at Level 6 for efficiency, it also meets the highest current level of energy efficiency standards.

Performance

Charger compatibility: Universal
Power source type: AC
USB 2.0 ports quantity: 1
USB Type-C ports quantity: 1
Feature: Fast charging
Fast charging technology: Power Delivery 3.0
Charger type: Indoor
Number of simultaneously connected devices (max): 2
Feature: Programmable power supply (PPS)
Feature: USB Power Delivery (USB PD)
USB Power Delivery revision: 3.0
USB Power Delivery up to: 65 W
Power protection features: Over current, Over voltage, Overheating, Short circuit

Design

Product colour: White
Housing material: Polyvinyl chloride (PVC), Polycarbonate (PC)
Connector material: Copper
Feature: Gallium nitride (GaN) transistors

Power

Input voltage: 100 - 240 V
Input frequency: 50/60 Hz
Input current: 1.5 A
Maximum power: 65 W
Maximum output voltage: 20 V
Minimum output voltage: 5 V
Output voltage accuracy (±): 5%
Output current (5V): 3 A
Output current (9V): 3 A
Output current (12V): 3 A
Output current (15V): 3 A
Output current (20V): 3.25 A
Power consumption (no load): 0.1 W
Average active efficiency: 81.38%
Feature: Efficiency at low load (10%)

Weight & dimensions

Width: 26.8 mm
Depth: 85.3 mm
Height: 41.6 mm
Weight: 40 g

Packaging data

Package width: 80 mm
Package depth: 100 mm
Package height: 45 mm
Package weight: 60 g
Package type: Carton

Operational conditions

Operating temperature (T-T): 0 - 25 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 20 - 90%
Storage relative humidity (H-H): 20 - 90%

Packaging content

Quantity per pack: 1 pc(s)
Feature: Manual

Certificates

Compliance certificates: CE, REACH, RoHS

Sustainability

Feature: Sustainability compliance
Sustainability certificates: ErP

Logistics data

Warranty period: 2 year(s)
