USB Extender - 100m 2 Port USB 2.0 Cat. 6 Extender 480Mbps
Product reference:
14-4002888434089
USB Extender - 100m 2-Port USB 2.0 Cat. 6 Extender, supporting two USB 2.0 devices up to 100 meters away using Cat.5e/6 cables, with 480Mbps bandwidth. Kit includes transmitter, receiver, power supply and mounting brackets.
USB Extender - 100m 2 Port USB 2.0 Cat. 6 Extender 480Mbps
Product reference:
14-4002888434089
USB Extender - 100m 2-Port USB 2.0 Cat. 6 Extender, supporting two USB 2.0 devices up to 100 meters away using Cat.5e/6 cables, with 480Mbps bandwidth. Kit includes transmitter, receiver, power supply and mounting brackets.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
100M 2 Port USB 2.0 Cat. 6 Extender 100M Extension for 2 USB Devices Powered Over Cat.6 Cable
Supports two USB 2.0 devices up to 100 meters away using Cat.5e/6 cables, with 480Mbps bandwidth. Includes transmitter and receiver, as well as power supply and mounting brackets.
- Extends USB 2.0 connection up to 100 meters (328.08ft) using Cat.6 cable.
- Supports high-speed data transfer with 480Mbps bandwidth.
- Two USB Type A outputs are included for connecting multiple devices.
- Offers Power Over Cable for easy setup and use.
Features | |
|---|---|
| Product Type | USB Extension Cable |
| Model | 100m 2 Port USB 2.0 Cat. 6 Extender |
Specifications | |
| USB Standard | USB 2.0 |
| Supported Bandwidth | 480Mbps |
| Maximum Distance | 100m (328.08ft) |
| Transmission Medium | Cat.5e/6 or higher network cable |
| Chipset | VA6000 |
| Special Features | Power over Cable; Supports control, bulk, interrupt and isochronous data transfer |
Connectors | |
| Transmitter Input | USB Type B (Female) |
| Transmitter Output | RJ45 (Female) |
| Receiver Input | RJ45 (Female) |
| Receiver Output | 2 x USB Type A (Female) |
| Power supply | 5.5/2.5mm DC jack |
Physical Properties | |
| Dimensions (WxDxH) | 82x49x20mm (3.23x1.93x0.79in) each |
| Housing | Metal |
| Net Weight | 0.2kg (0.44lb) |
| Operating Temperature | 0° - 40°C (32°F - 104°F) |
| Storage Temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20 - 90% RH (non-condensing) |
| Power Requirements | 12VDC 3A |
| Color | Black |
Miscellaneous | |
| Packaging Type | Cardboard Box |
| Packaging Dimensions | 200x115x75mm (7.87x4.53x2.95in) |
| Total Weight | 0.6kg (1.32lb) |
Safety Warning | |
| Use the product only for its intended purpose to avoid potential hazards. | |
