RigExpertAA-230 ZOOM
The analyzer is designed for measuring SWR (standing wave ratio), return loss, cable loss, as well as other parameters of cable and antenna systems in the range of 100 kHz to 230 MHz.
A built-in ZOOM capability makes graphical measurements especially effective.
An...
Specifications
Frequency range: 0.1 to 1500 MHz
Frequency entry: 1 kHz resolution
Measurement for 25, 50, 75, 100, 150, 200, 300, 450 and 600-Ohms systems
SWR measurement range: 1 to 100 in numerical mode, 1 to 10 in graph mode
R and X range: 0…2000, -2000…2000
Display modes: SWR, return...
( Užsakoma prekė, pristatymas per 9 dienas )
RigExpert AA-1400
RigExpert AA-600, AA-1000 and AA-1400 are powerful antenna analyzers designed for testing, checking, tuning or repairing antennas and antenna feedlines.
Graphical SWR (Standing Wave Ratio) and impedance, as well as Smith/polar...
MFJ VNA Antenna Analyzer covers 1 to 230 MHz, 1Hz resolution.
Frequency sweep plots: SWR, Impedance, Resistance, Reactance,Phase Angle, Complex Return Loss, Smith Chart
Sign of reactance
Amazing accuracy with OSL(Open-Short-Load) calibration.
New MFJ-226 introduces the MFJ Times...
( Užsakoma prekė, pristatymas per 9 dienas )
RigExpert AA-1000
RigExpert AA-600, AA-1000 and AA-1400 are powerful antenna analyzers designed for testing, checking, tuning or repairing antennas and antenna feedlines.
Graphical SWR (Standing Wave Ratio) and impedance, as well as Smith/polar...
( Užsakoma prekė, pristatymas per 9 dienas )
RigExpert AA-600
RigExpert AA-600, AA-1000 and AA-1400 are powerful antenna analyzer designed for testing, checking, tuning or repairing antennas and antenna feedlines.
Graphical SWR (Standing Wave Ratio) and impedance, as well as Smith/polar...
The SX1100 measures forward and reflected power and VSWR. Compact size makes meter useful for testing both base and mobile installations. Two directional couplers with switch and LED indicators for in-line connection of two transceivers.
Special Features:
Illuminated meter
Switchable r.m.s....
The SX600 measures forward and reflected power and VSWR. Compact size makes meter useful for testing both base and mobile installations. Two directional couplers with switch and LED indicators for in-line connection of two transceivers.
Special Features:
Illuminated meter
Switchable r.m.s....
The SX200 measures forward and reflected power and VSWR. Compact size makes meter useful for testing both base and mobile installations.
Special Features:
Illuminated meter
Switchable r.m.s. or peak power
Measures forward, reflected & SWR power
6"W x 2"H x 4"D, 2 lbs....
The SX400 measures forward and reflected power and VSWR. Compact size makes meter useful for testing both base and mobile installations.
Special Features:
Illuminated meter
Switchable r.m.s. or peak power
Measures forward, reflected & VSWR power
6"W x 2"H x 4"D, 2 lbs....
The SX100 measures forward and reflected power and VSWR. Compact size makes meter useful for testing both base and mobile installations.
Special Features:
Illuminated meter*
Switchable r.m.s. or peak power
Measures forward, reflected & VSWR power
6"W x 2"H x 4"D, 2 lbs....
MFJ-260C 300W/50ohm antenos ekvivalentas.
The MFJ-260C is an air cooled, non-inductive resistor in a perforated metal housing. It has SO-239 connectors. You can handle a full load for 30 seconds. Silk-screened derating curve to 5 minutes. Handles 300 Watts. SWR below 1.1:1 to 30 MHz, 1.5:1 from...
MFJ-99C 10-Pack SuperCell Ni-MH batteries & MFJ-1312D 110/220 VAC Power supply
MFJ-39DAC Has MFJ-39D custom Carrying Pouch for MFJ-269C/CM, MFJ-1312D power cube, and MFJ-66 dip coils.
MFJ-39DABC Pouch, Batteries, Coils, Power cube.
MFJ-92AA10 10-Pack AA SuperCell Rechargeable Ni-MH...
DL-30A MFJ-261 15W/50ohm antenna equivalent
Specification:
Frequency band up to 1000Mhz
Resistance 50 OM
Connector type PL259
SWR 1.15 or less (Dc-800Mhz), 1.20 (800-1000Mhz)
Allowed power 15W continuously, 20W for 5 minutes, 50W for 1 minute, 100W for 30 seconds
Weight 109g.
