UBIQUITI UniFi AC HD 802.11ac Wave 2 Enterprise Wi-Fi Access Point
Product reference: 18-UAP-AC-HD

UBIQUITI UniFi AC HD 802.11ac Wave 2 Enterprise Wi-Fi Access Point

UBIQUITI UniFi AC HD 802.11ac Wave 2 Enterprise Wi-Fi Access Point

Product reference: 18-UAP-AC-HD

UBIQUITI UniFi AC HD 802.11ac Wave 2 Enterprise Wi-Fi Access Point

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
32399
Last product in warehouse

Guarantee
12 month

Delivery from Lithuania in
2 - 3
business days

Your message has been successfully sent!
Fill in the required fields*

Deploy the UniFi AC HD AP in high-density environments requiring maximum wireless performance. The UniFi AC HD AP features simultaneous, dual-band, 4x4 MU-MIMO technology and convenient 802.3at PoE+ compatibility.


Easy Mounting Its sleek design seamlessly integrates into any environment (all accessories included) and is compatible with existing UAP-AC-PRO mounts.


LED Unique LED provisioning ring provides administrator location tracking and alerts for each device.


Dual Gigabit Ethernet The UniFi AC HD AP offers a secondary port available for bridging.


Superior Processing Power The UniFi AC HD AP is capable of complex operations (guest control, filtering, and other resource-intensive tasks) that may slow down a lesser-equipped AP.


Power over Ethernet (PoE) Includes PoE functionality. Each single-pack includes a PoE adapter.


PoE Standard The UniFi AC HD AP is compatible with an 802.3at PoE+ compliant switch. We recommend powering your UniFi devices with a UniFi PoE Switch (sold separately).


UniFi PoE Switch Available in 8, 16, 24, and 48-port versions with multiple power output options, the UniFi PoE Switch conveniently offers auto-sensing IEEE 802.3af PoE/802.3at PoE+.






























































































































UAP-AC-HD
Dimensions220 x 220 x 48.1 mm
Weight with Mounting Kits700 g (24.7 oz) 830 g (29.3 oz)
Network Interface(2) 10/100/1000 Ethernet Ports
Ports(2) Ethernet RJ45, (1) USB Type C
ButtonsReset
Antennas(2) 2.4G internal single band antennas, dual polarity (2) 5G internal single band antennas, dual polarity
Wi-Fi Standards802.11a/b/g/n/ac/ac-wave2
Power MethodPoE 802.3at
Power SupplyPoE Injector 48VDC -0.5A Gigabit
Maximum Power Consumption17W
Max TX Power25 dBm
BSSID4 On the Radio
Power SaveSupported
Wireless SecurityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
CertificationsCE, FCC, IC
MountingWall/Ceiling (Kits Included)
Operating Temperature-10 to 70°C (14 to 158°F)
Operating Humidity5 to 95% Non-condensing
Advanced Traffic Management
VLANs802.1Q
Advanced QoSPer-User Rate Limiting
Guest Traffic IsolationSupported
WMMSupported
Concurrent Clients500+
Supported Data Rates (Mbps)
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11ac6.5 Mbps to 1.7Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
