UBIQUITI Access Reader G3, White

Advanced Access ControlThe Ubiquiti G3 Access Reader White (UA-G3-W) is an access control device designed to enhance security and streamline entry management. It supports multiple authentication methods, including NFC cards, the UniFi Identity mobile app, and Apple Touch Pass, providing flexible and secure access options. Additionally, the reader features a proximity sensor for hand-wave unlocking, facilitating touchless entry and improving user convenience. This versatility ensures that the UA-G3-W can be seamlessly integrated into various security systems, offering a comprehensive solution for modern access control needs. The G3 Access Reader integrates seamlessly with the UniFi Access Hub via Power over Ethernet (PoE), simplifying installation and reducing the need for additional power sources. This integration allows for centralized management and monitoring through the UniFi Access application, enabling administrators to configure access permissions, monitor entry logs, and receive real-time alerts. The user-friendly interface of the UniFi Access application enhances the overall management experience, providing a comprehensive solution for access control needs.

Robust Performance and Durable DesignThe UA-G3-W is engineered to provide a seamless and user-friendly experience, ensuring that every access attempt is met with clear and immediate feedback. Equipped with an 8-ohm, 0.7W speaker, the reader produces crisp and audible notifications. In addition to the audio signals, the G3 Access Reader features multi-color LEDs (Red, Green, Blue, and White) that visually indicate the access status. The LED lights offer intuitive guidance, with green typically indicating access granted, red signaling a denied attempt, and blue or white providing system status or additional cues. This visual feedback is crucial in high-traffic areas or environments with high noise levels. The G3 Access Reader is built to withstand various environmental conditions. Its IP55-rated enclosure ensures reliable performance in outdoor settings, withstanding temperatures ranging from -30°C to 45°C. The polycarbonate and glass construction, combined with aluminum alloy mounting materials, provides a sturdy and weather-resistant design suitable for various installation environments. This robust build guarantees the reader's longevity and consistent operation, even in challenging weather conditions.

Dimensions: 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4') NFC Card Keyfob Access: Yes Touch Pass: Yes Mobile Unlock: Yes Handwave Request to Exit: Yes Weatherproofing: IP55

Mechanical

Weight: 82 g (2.9 oz) Enclosure Material: Polycarbonate, glass Mount Material: Aluminum alloy Mounting: In-wall, gang box (Included) Junction box (Optional)

Hardware

Indoor and Outdoor Use: Yes Ambient Operating Temperature: -30 to 45° C (-22 to 113° F) Ambient Operating Humidity: 5 to 90% noncondensing Networking Interface: (1) 10/100 MbE RJ45 port Connectivity: BLE 4.1 NFC Power Method: PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU Max. Power Consumption: 5W Supported Voltage Range: 48V DC ESD/EMP Protection: Air: ±15kV, contact: ±8kV Sensors: Proximity sensor Speaker: Yes LEDs: R/G/B/WLearn MoreButton: (1) Factory-reset NFC Frequency: 13.56 MHz NFC Read Range: < 30 mm (1.18'') NFC Technology: ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0 PoE Cabling Requirements: Cat 5e cabling is the minimum performance category recommended. The performance category used should match the transmission speed required at the installation site. The minimum conductor gauge allowed to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm²) for patch cords; 24 AWG (0.21 mm²) for horizontal or riser cable. UL 294 Level: Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I UL 294 Statement: Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. CAN/ULC-60839-11-1 Grade: Grade assignment: I Certifications: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 Document number, and issue date and/or revision level: UA-G3, V01 NDAA Compliant: Yes

Software

Management Application: Access Software Information: The software version can be checked athttps://unifi.ui.com
