Switch, UBIQUITI, WAN Switch RJ45, USW-WAN-RJ45

Product reference: 2-810177160120

You have 3 products in compare list, please remove someone and try again

Add to compare

23853 €

Product in warehouse

Guarantee
12 month

Delivery from Lithuania in
3 - 5
business days

10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

Summary	Ubiquiti UniFi WAN Switch RJ45. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 1. Switching capacity: 20 Gbit/s. Power connector: AC/DC. Rack mounting, Form factor: 1U
Vendor Homepage	https://eu.store.ui.com/eu/en/category/switching-wan/products/usw-wan-rj45
Unit Box Height	0.245
Unit Box Length	0.54
Unit Box Width	0.105
10G Ethernet (copper) ports quantity	3
Basic switching RJ-45 Ethernet ports quantity	1
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	1
Power cables quantity	2
Power connector	AC/DC
10G support	Yes
Forwarding rate	15 Mpps
Switching capacity	20 Gbit/s
Throughput	10 Gbit/s
Form factor	1U
Housing material	SGCC
LED indicators	Network/System
Product colour	Grey
Rack mounting	Yes
Reset button	Yes
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Power consumption (max)	18 W
Power source	AC/DC
Power supply included	Yes
Power over Ethernet (PoE)	No
Operating relative humidity (H-H)	10 - 90 %
Operating temperature (T-T)	-5 - 40 °C
Depth	120 mm
Height	43.7 mm
Weight	2300 g
Width	442.4 mm
Cables included	Power
Rack mount kit	Yes
Compliance certificates	CE/Federal Communications Commission (FCC)/Industry Canada (IC)/National Defense Authorization Act (NDAA)
Model	USW-WAN-RJ45
Model name	WAN Switch RJ45
Units per Shipping Box	4
Unit Calculated Volume	0.01689 cubm
Unit Calculated Weight	3.7 kg
